- Page 1 IP Card Reader - Upgrade Work Instruction | IP Card Reader - Upgrade © 2019 Inepro B.V. All rights reserved...
- Page 2 We want to help you get the best result from your IP Card Reader - Upgrade . This manual contains information on how to do that; please read it carefully. Due to continuous product improvements this manual is subject to changes without notice.
- Page 3 IP Card Reader - Upgrade All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.
-
Page 4: Table Of Contents
Table of Contents Introduction Package Content Software Installation Hardware Installation Programming Instructions Troubleshooting... - Page 5 End of life dir ectives Inepro is pay ing a lot of attention to env ironmentally -friendly production. Your new dev ice contain materials w hich can be recy cled and reused. A t the end of its life specialised companies can dismantle the discarded dev ice to recy cle the reusable materials and to minimise the amount of materials to be disposed of.
-
Page 6: Introduction
Introduction Part... - Page 7 Introduction Introduction This short manual will guide you trough the upgrade process of the Inepro IP Card Reader. Please follow the instructions closely.
-
Page 8: Package Content
Package Content Part... - Page 9 Package Content Package Content Inepro IP Card Reader Interface Package 1. Flat cable for communication between the programmer and interface board 2. USB cable for connection with the PC 3. Melabs U2 Instruction Sheet 4. Melabs U2 Setup CD 5. Melabs U2 Programmer Unit...
-
Page 10: Software Installation
Software Installation Part... - Page 11 Software Installation Software Installation 1. First setup the Melabs programmer software application. 2. Please insert the installation CD. 3. Choose 'Execute Setup.exe' 4. Click 'Next' 5. Choose 'I accept the agreement' 6. Click 'Next' 7. Click 'Next' 8. Click 'Install'...
- Page 12 9. Wait for the installation to finish 10. Click 'Next', ticking the boxes is optional 11. Read the information, and click 'Next' 12. Finish the installation IP Card Reader - Upgrade...
-
Page 13: Hardware Installation
Hardware Installation Part... - Page 14 Hardware Installation 1. Screw the Inepro IP Card Reader box open and take out the Interface connector board. IP Card Reader - Upgrade...
- Page 15 Hardware Installation 2) Connect the USB cable to the PC you installed the software on and the programmer unit. 3) Connect the black connector of the flat cable to the programmer unit in such a way that the red side of the cable is on the left side (this is the same side as pin 1 on the diagram on the programmer).
- Page 16 PoE connector on the board. The Power over Ethernet option requires the implementation of Power over Ethernet in your network, otherwise no power can be supplied. The power adapter was supplied together with the Inepro IP Card Reader. IP Card Reader - Upgrade...
-
Page 17: Programming Instructions
Programming Instructions Part... - Page 18 Programming Instructions To program the Inepro IP Card Reader, you need a hex-file. This file should be supplied by Inepro and is customized to meet your requirements. 1. Start the mePROG.exe executable. 2. Choose 'File' -> 'Open'. 3. Open the hex-file that Inepro supplied. The selected hex filename will be shown in the title bar of the application window.
- Page 19 Programming Instructions 4. Set all the ticks in the 'Options', 'More Options' and 'Program' submenu's as shown in the image above.
- Page 20 5. Tick all the options in the 'Verify' menu, as shown in the image above. IP Card Reader - Upgrade...
- Page 21 Programming Instructions 6. Tick all the options in the 'Blank Check' menu, as shown in the image above.
- Page 22 7. Tick all the options in the 'Erase' menu, as shown in the image above. IP Card Reader - Upgrade...
- Page 23 Programming Instructions 8. Choose 'Program' -> 'Determine Target Device' to connect the device to the application. Make sure that you remove the card reader from the interface board, to prevent errors! 10. Choose 'Program' -> 'Program'...
- Page 24 LED's will blink. 12. The Interface board has now been programmed and is ready for use. If you disconnected a reader at step 9, you may now reconnect it again. IP Card Reader - Upgrade...
-
Page 25: Troubleshooting
Troubleshooting Part... - Page 26 For more information see page c) Try to execute the program procedure on page 2) The board is empty or defect. a) Replace the interface board. 1) There is no programmer detected a) Check the cables. IP Card Reader - Upgrade...
- Page 27 Troubleshooting <This page is intentionally left blank>...
