Summary of Contents for Inepro SCR708
- Page 1 SCR708 Technical Manual | SCR708 Product Version: Rev.1 Version of this manual: 1.0.10 © 2017 Inepro B.V. All rights reserved...
- Page 3 We want to help you get the best result from your Inepro card reader. This manual contains information on how to do that; please read it carefully. Due to continuous product improvements this manual is subject to changes without notice.
- Page 4 SCR708 All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.
-
Page 5: Table Of Contents
Table of Contents Introduction Requirements Components Optional Components Test Software ................................ 12 Hardware ................................ 13 User Interface LED's ................................ 16 Technical Specifications Troubleshooting Appendices Appendix I ................................ 22 Notes Notes END-USER LICENSE AGREEMENT http://www.inepro.com... - Page 7 End of life directives Inepro is paying a lot of attention to environmentally-friendly production. Your new device contain materials which can be recycled and reused. At the end of its life specialised companies can dismantle the discarded device to recycle the reusable materials and to minimise the amount of materials to be disposed of.
-
Page 9: Introduction
Introduction Part... - Page 10 Introduction Introduction In this manual you find the instructions to install and configure your SCR708. This manual is meant for all the Inepro USB RFID Readers. This manual, the USB RFID Reader hardware and software are subject to change, make sure you have the latest version of this manual, because the older versions may have become obsolete.
-
Page 11: Requirements
Requirements Part... - Page 12 Requirements Requirements The USB RFID Reader has no known requirements other than a USB host that can read a keyboard-like Human Interface Device SCR708...
-
Page 13: Components
Components Part... - Page 14 § P520215 - Ferrite core for round cable 227 Ohms - 100MHz § P500943 - Double-sided adhesive tape SCR708 - 50x22x0.1mm § § P279202 - SCR708 USB A - Micro B cable 1.80M § P551211 - Download instructions Check Components Please check if all the components are in the set before you continue with the installation and setup.
-
Page 15: Optional Components
Optional Components Part... - Page 16 SCR708 Bracket Set The SCR708 can be used on a MFP (a Multi Functional Printer). It can be placed inside or stuck to the exterior with tape. For a more elegant solution a bracket set is available: SCR708 Bracket - Art. Nr.: 400001 Follow steps 1-4 to assemble the bracket.
- Page 17 This cable is needed when a USB OTG (On The Go) connection is used in the MFP. The cable is available at a length of 0.5m or 1.8m. SCR708 USB Mini B - Micro B OTG cable 0.50m - P279211 / SCR708 USB Mini B - Micro B OTG cable 1.80m - P279212 These can be ordered with your supplier of Inepro products Version 1.0.10...
-
Page 19: Test
Test Part... -
Page 20: Software
Software For the SCR708 there are 2 tools available each with its specific features. Connect the SCR708 to a computer or laptop and present a card to the reader. Please note that the reader needs to have the HID RAW Configuration. (See Omni RFID Program tool manual for more details). -
Page 21: Hardware
Hardware Physical test Inepro USB RFID Reader 1. Connect the Inepro USB RFID Reader to the USB port of a computer. 2. Check the indicator LED's to see if the board is operating as it should. Put a card on the SCR708:... -
Page 23: User Interface
User Interface Part... -
Page 24: Led's
On the USB interface board are a number of LED’s. Each of the LED's has a label, explaining their use. See the table below Image Function Standby / Triggered / Normal Not OK Card is not recognized Card in detection field Card Recognized Reader is on Flashes and connected (no connection) SCR708... -
Page 25: Technical Specifications
Technical Specifications Part... - Page 26 Red, Yellow/Orange, Green and Blue Audio Piezo Buzzer 4kHz, 17 x 4.5mm, Max. 80 dB Environmental conditions EMI / Safety CE, FCC Class A Operating Temperature (Metric) 0-40 degrees Celsius Operating Temperature (Non-Metric) 32-104 degrees Fahrenheit Relative Humidity (Non Condensing) 10%-90% SCR708...
-
Page 27: Troubleshooting
Troubleshooting VIII Part... - Page 28 The section is set up in a Symptom - Prognosis - Resolution format, that is first the symptom is given, then the possible causes and then the resolution for those causes. Symptom(s): Card not recognized Prognosis: The SCR708 is not connected Scope: All Devices Resolution: A - Check if the blue light is flashing, if it is the reader is not connected to the server.
-
Page 29: Appendices
Appendices Part... - Page 30 Appendices Appendix I: Connection Cable SCR708...
-
Page 31: Notes
Notes Part... -
Page 32: Notes
Notes Notes This area is meant for the reader's notes: SCR708... - Page 33 Notes Part...
- Page 34 Notes Notes This area is meant for the reader's notes: SCR708...
-
Page 35: End-User License Agreement
7. Update Checks. You acknowledge and agree to allow Inepro Back Office Suite version and license status details to be sent to Inepro BV when you request to "Check for updates". This allows the Inepro Back Office Suite software to determine whether software updates are available in real-time.
