- Page 1 Inepro IP Reader V2 Technical Manual | Inepro IP Reader V2 Product Version: Rev.3 - V2 Version of this manual: 2.1.1 © 2014 Inepro B.V. All rights reserved...
- Page 3 We want to help you get the best result from your Inepro Back Office Suite. This manual contains information on how to do that; please read it carefully. Due to continuous product improvements this manual is subject to changes without notice.
- Page 4 Inepro IP Reader V2 Inepro IP Reader V2 All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.
-
Page 5: Table Of Contents
Table of Contents Introduction Components Operating Procedures Network Connections LEDs (Light Emitting Diodes) Hardware installation Software configuration settings Specifications Appendix I... - Page 7 This device is in conformity with the EMC directive and low-voltage directive. End of life directives Inepro is paying a lot of attention to environmentally-friendly production. Your new device contain materials which can be recycled and reused. At the end of its life specialised companies can dismantle the discarded device to recycle the reusable materials and to minimise the amount of materials to be disposed of.
-
Page 9: Introduction
Introduction Part... - Page 10 Introduction In this manual you find the instructions to install and configure your IP-reader. This manual is meant for all the Inepro IP-readers. This manual, the IP reader hardware and software are subject to change, make sure you have the latest version of this manual, because the older versions may have become obsolete.
-
Page 11: Components
Components Part... - Page 12 · Wire Duct - Grey · Network Cables - Network Cable UTP C5E Patch Black (0,5mtr.) - Network Cable UTP C5E Patch Black (2,0mtr.) · Power Supply AC/DC 12 Volts, 7 Watt - Power Supply Unit - 3x Socket Adapter Inepro IP Reader V2...
- Page 13 Components · Screw set - 2x Screw self tapping cross head dome 3,5 x 9,5 mm · Download Guide Inepro Manuals Check Components Please check if all the components are in the set before you continue with the installation and setup.
-
Page 15: Operating Procedures
Operating Procedures Part... - Page 16 Ethernet connection. The server will receive the card’s data and returns an (error) code to the IP controller board. The IP controller board will show this code through the LED's in the card reader’s housing. Inepro IP Reader V2...
-
Page 17: Network Connections
Network Connections Part... - Page 18 "no PoE" Ethernet connector), nothing will be damaged. In that case the IP controller won't have energy and will not operate. Switching the Ethernet cable to the "PoE" connector will activate the IP controller board. Inepro IP Reader V2...
- Page 19 Network Connections IP READER OVERVIEW Power over Ethernet No Power over Ethernet Orange LED = Blinking Orange LED = On Green LED = On Green LED = Blinking IP Controller Board Ethernet Connections IP Controller Board IP Controller Board LED's RS232 Led on = Communication between -->...
-
Page 21: Leds (Light Emitting Diodes)
LEDs (Light Emitting Diodes) Part... - Page 22 Blink patterns In case of an error situation the LED will blink with an irregular pattern. The number of times the LED blinks between the longer 'on' (or 'off') pulses is an indication for the error code. Inepro IP Reader V2...
- Page 23 LEDs (Light Emitting Diodes) Reader Status Display Waiting Card presented to reader, but no reaction from Contant on/off pattern Non-Wiegand server (0.5 sec. / 0.5 sec.) Contant on/off pattern Card presented to reader, but no reaction from Wiegand (0.5 sec. / 0.5 sec.) for 30 server seconds.
- Page 24 The IP controller board will receive this data string and, after encryption, redirect this data to the server. This situation can cause the CARD LED and the RS232 LED to behave differently. Inepro IP Reader V2...
- Page 25 LEDs (Light Emitting Diodes) IP Controller Board Ethernet Connector LED's On each of the 2 Ethernet connectors on the IP controller board 2 LEDs are mounted with the same way of operating as a network switch/router. Status Display Connection Green exists orange Connection...
-
Page 27: Hardware Installation
Hardware installation Part... - Page 28 Hardware installation · Make sure the print board is securely connected in the housing. · Connect the antenne board to the IP Reader Print board and use the cable clip to secure the cable to the housing. Inepro IP Reader V2...
- Page 29 Hardware installation Network with PoE (power over Internet) · Connect the network cable to the network connector marked PoE (the rightmost network connector in the picture above). Version 2.1.1...
- Page 30 / or use the screws to attach it even more firmly. · Place the cover over the screw holes. · Strip the protection from the adhesive tape and use (parts) of the cable guides, to guide the cable to the back of the machine. Inepro IP Reader V2...
- Page 31 Hardware installation Place the IP-Card Reader print board Attachment the IP-Card Reader print board with Velcro · Clean the surface of the machine and the covers. · Place the velcro on the covers and the machine. · Place the IP-Reader Board on the velcro on the machine.
- Page 32 Attachment the IP-Card Reader print board with screws · Use the two self tapping screws to secure the bottom cover to the machine. Inepro IP Reader V2...
-
Page 33: Software Configuration Settings
Software configuration settings Part... - Page 34 Key set will give the possibility to set the encryption key between the IP reader Key set and the server. At the time of writing the value as not yet used and should always be set to '1'. Inepro IP Reader V2...
- Page 35 Software configuration settings Reader config settings Description Setting 1 Setting 2 Setting 3 These settings will be addressed below. Data 1 Data 2 These fields will be used for retrieving the card reader data. The values entered here are dependent on the card that is used. Note: The raw data is supplied without conversion.
- Page 36 IP reader will check if the code on the card is present. If the value is '0' the facility code is not checked. Data 1 Not applicable Data 2 Not applicable Note: The facility code is never send to the server. Inepro IP Reader V2...
- Page 37 Software configuration settings Multi tag: Setting Description Value Card Types Behaviour EM4x50, hitag1, hitag2, Q5 and Ti-RFID EM4x02, EM4x05, IP reader will read the EM4x50, hitag1, following protocols: hitag2 and Ti-RFID EM4x02, EM4x05, EM4x02, EM4x05, The card data of the EM4x50, hitag1, hitag2, Q5 EM4x50, hitag1, EM4x02 cards will be...
- Page 38 Not applicable Data 2 Not applicable Note: When you can't find your card reader type in these tables, please contact Inepro for the settings for your reader. They will send you the latest version of this manual. Inepro IP Reader V2...
-
Page 39: Specifications
Specifications VIII Part... - Page 40 Connector (Both) Confirm IEEE 802.3, 100Base-T Network Interface (Both) Transmission Speed (Both) 100 Mbps Power over Internet (PoE) Confirm IEEE 802.3 AF DHCP client or static IP IP-Address Environmental conditions Suitable for indoor use only Operating Requirements Inepro IP Reader V2...
- Page 41 Specifications <This page is blank intentionally> Version 2.1.1...
- Page 42 <This page is blank intentionally> Inepro IP Reader V2...
- Page 43 Specifications <This page is blank intentionally> Version 2.1.1...
-
Page 45: Appendix I
Appendix I Part... - Page 46 Inepro IP Reader V2...
