Xycom XVME-212 Manual page 53

XVME-2 12 Manual
August, 1989
Connector
Signal and
Mnemonic Pin Number
SYSFAIL* 1C:lO
SYSRESET* lC:12
WRITE* lA:14
+5V STDBY lB:31
+5V 1 A:32
lB:32
1 C:32
2B:1,13,32
+12V 1C:31
-12v lA:31
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table B-l. VMEbus Signal Identification (cont'd)
Signal Name and Description
SYSTEM,FAIL: Open-collector driven signal that indicates
that a failure has occurred in the system. It may be
generated by any module on the VMEbus.
SYSTEM RESET: Open-collector driven signal which, when
low, will cause the system to be reset.
WRITE: Three-state driven signal that specifies the data
transfer cycle in progress to be either read or written. A
high level indicates a read operation, a low level indicates
a write operation.
+5 VDC STANDBY: This line supplies +5 VDC to devices
requiring battery backup.
+5 VDC POWER: Used by system logic circuits.
+12 VDC POWER: Used by system logic circuits.
-12 VDC POWER: Used by system logic circuits.
B-5
