2.4 JUMPERS/SWITCHES

Prior to installing the XVME-212, it is necessary to choose several jumper/switch
selectable options. These options fall into two categories: VMEbus-related options and
debounce period jumpers.
VMEbus Options
- Module base address, selected by switches l-6 of the Address Switches (Sl)
- Privilege level required to access the module, selected by Switch 7 of the Address
Switches (Sl)
- VMEbus interrupt level, selected by the Interrupt Level Switches (S2)
- Whether to use or bypass the IACK daisy chain, selected by Jumpers Jl and J2
Debounce Period Jumpers
The length of the debounce period is selected by Jumpers J4 and Jl1.
-
