Xycom XVME-212 Manual page 10

XVME-2 12 Manual
August, 1989
Table l-l. XVME-2 12 Module Specifications (cont'd)
Characteristic
Isolation
Board Dimensions
Environmental Specifications
Temperature
Operating
Non-operating
Humidity
Altitude
Operating
Non-operating
Vibration
Operating
Non-operating
Shock
Operating
Non-operating
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Specification
300 VDC channel-to-channel
300 VDC channel to VMEbus ground
NEXP board size
(160mm x 233.4mm)
5 to 95% RH, non-condensing
(Extremely low humidity conditions may
require special protection against static
discharge.)
Sea level to 20,000 ft.
(6096m)
Sea level to 50,000 ft.
(15240m)
5 to 2000 Hz
.O 15" peak-to-peak displacement
2.5g peak acceleration
5 to 2000 Hz
.030" peak-to peak displacement
5.0 g peak (maximum) acceleration
30 g peak acceleration,
11 msec duration
50 g peak acceleration,
11 msec duration
1-4
