PART NAMES

FRONT
BACK
1
Main Unit
2
Air Outlet
OFF TIMER Button, Indicator Light (white)
3
(Press 3 sec.) Filter Reset Button, Indicator Light (orange)
MODE Button, Indicator Light (white)
4
(Press 3 sec.) Plasmacluster Ion ON/OFF Button
5
HAZE Button, indicator Light (white)
6
POWER ON/OFF Button
7
Light Sensor
8
Odor Sensor
9
Plasmaclustor Ion Light (blue)
OM_FP-J40E_40L_EN.indd 4
3
2
1
10
Cleanliness Monitor
Indicates the air purity of the room
in 3 levels with color changes.
14
15
16
4 5
9
Blue
Orange
Red
11
12
13
18
17
10
Cleanliness Monitor
11
Handle
12
Dust Sensor Filter
13
HEPA Filter
14
Deodorizing Filter
15
Back Panel (Pre-Filter)
16
Bottom Tabs
Plug
17
(Shape of plug depends on country.)
18
Power Cord
EN-4
6
7
8
Clean
Impure
