TROUBLESHOOTING

Before calling for service, please review the Troubleshooting chart below, since the problem may not be a unit
malfunction.
SYMPTOM
Odors and smoke are not removed.
The Cleanliness Monitor illuminates blue
even when the air is impure.
The Cleanliness Monitor illuminates
orange or red even when the air is clean.
A clicking or ticking sound is heard from
the main unit.
The discharged air has an odor.
The unit does not operate properly when
cigarette smoke is in the air.
The Cleanliness Monitor is turned off.
The Cleanliness Monitor lights change
color frequently.
The SLEEP lamp is flashing.
AUTO RESTART
After a power failure, automatically
resume the operation when the power
recovers.
ON
(with the main unit OFF)
(simultaneously for
more than 3 sec.)
OM_FP-J40E_40L_EN.indd 10
• Replace the filters if they appear to be heavily soiled. (page 9)
• The air could be impure at the time the main unit was plugged in.
Unplug the main unit, wait one minute, and plug the main unit in again.
• Sensor operation is affected if the dust sensor openings are dirty or
clogged. Gently clean the dust sensor openings. (page 8).
• Clicking or ticking sounds may be audible when the main unit is
generating ions.
• Check to see if the filters are heavily soiled.
• Clean or replace the filters.
• Plasmacluster Air Purifiers emit small traces of ozone which may produce
an odor.
• Is the unit installed in a location that is difficult for the sensor to detect
cigarette smoke?
• Is the dust sensor opening blocked or clogged?
(In this case, clean the opening.) (page 8)
• Check to see if the Lights OFF Mode selected.
Press for 3 seconds to light On. (page 7)
• Check to see if the SLEEP mode is selected.
The Cleanliness Monitor/ Plasmaclustor Ion Light are turned off
automatically after the SLEEP mode is selected.
• The Cleanliness Monitor lights automatically change colors as impurities
are detected by the dust sensor.
• Fan motor error. Turn the power OFF.
Wait one minute, and then turn the power ON.
Auto Restart can be set.
•
Even when the plug is unplugged or the breaker is thrown during the
operation, the operation resumes at the previous operation mode and
settings if the power recovers.
If the , , , lamp Lights up
for 8 seconds, the setting is completed.
EN-10
REMEDY (not a malfunction)
OFF
(with the main unit OFF)
(simultaneously for
more than 3 sec.)
