Assembling the Christie
One aluminum rigging
frame
With the Christie One aluminum rigging frame (P/N: 140-137102-01), the projector can be secured to
trusses or structures built for the purpose of positioning the projector.
With the frame:
•
Up to three projectors can be stacked in landscape orientation.
•
A single projector can be positioned in portrait mode but no stacking is permitted.
Christie ships the frame separately from the projector.
Affected products
The Christie One rigging frame is designed for use with the following projectors.
•
HS Series projectors (D13WU-HS, D13HD-HS, D16WU-HS, D16HD-HS, D20WU-HS, D20HD-
HS, 4K7-HS, and 4K10-HS)
Safety warnings and guidelines
Read all safety and warning guidelines before starting this procedure.
Danger! If not avoided, the following results in death or serious injury.
•
Do not stack the device unless specified in this manual.
•
The supporting structure must safely support the combined load of the product, all attached
hardware, and components following all local safety standards and regulations.
•
Use all mounting points, including the safety point, when installing the product overhead.
Warning! If not avoided, the following could result in death or serious injury.
•
Only use this frame with the specified products.
•
Safety straps must be used when stacking two or more rigging frames.
•
Always install safety straps when the frame and projector are installed overhead.
•
Do not stack empty frames.
•
Projectors must be installed in frames before stacking.
Notice. If not avoided, the following could result in property damage.
•
Use appropriate packaging when shipping the product installed in the frame.
Assembling the Christie One Frame Instruction Sheet
020-103043-01 Rev. 1 (05-2019)
Copyright
2019 Christie Digital Systems USA, Inc. All rights reserved.
©
1
Advertisement
Table of Contents
Related Manuals for Christie One
Summary of Contents for Christie One
- Page 1 Assembling the Christie One aluminum rigging frame With the Christie One aluminum rigging frame (P/N: 140-137102-01), the projector can be secured to trusses or structures built for the purpose of positioning the projector. With the frame: • Up to three projectors can be stacked in landscape orientation.
- Page 2 Optional tools • Adjustment tool provided with the Christie One aluminum rigging frame Physical specifications Learn the weight and physical dimensions of the Christie One rigging frame. • Weight: 30 kg (66 lbs) • Dimensions: 850 x 756 x 466 mm (H) Securing the projector to the stacking frame Secure the projector to the stacking frame before stacking additional projectors.
- Page 3 The M8 bolts must be tightened to a torque of 38 Nm. Refer to the image below for the mounting points on the base plate for each projector series. Assembling the Christie One Frame Instruction Sheet 020-103043-01 Rev. 1 (05-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...
- Page 4 Projectors must be installed in frames before stacking. 1. Remove the locking pins from each stacking leg. 2. With one person positioned on each side of the framed projector, lift the assembly and place it onto the bottom frame. Stacking in portrait orientation is not permitted 3.
- Page 5 6. When stacking a third framed projector, repeat steps 1 to 4. Aligning stacked projectors Stacked projectors must be correctly aligned to one another to achieve an optimally displayed image. 1. Hoist and secure a stack of projectors before aligning.
- Page 6 The pin limits the adjustment within the useful range. 6. To lock adjustments, tighten the setscrews on each adjustment knob. Assembling the Christie One Frame Instruction Sheet 020-103043-01 Rev. 1 (05-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...
