Materials Included:
Part #
Description
1
5" sq. x 84"
2
84" Long molded arches
3
5" sq. Locking arch/post inserts
4
5" sq. Trim caps
5
1 3/4" x 3 1/2" Pergola end caps
6
2" x 3 1/2" x 31 3/4" Bottom rails
7
1 3/4" sq. x 41 5/8" Middle rails
8
41 5/8" Long curved top rails
9
1 3/4" x 3 1/2" x 46 1/2" Filters
10
7/8" x 1 1/2" x 56" Spindles
7/8" x 1 1/2" x 53 1/2" Spindles
7/8" x 1 1/2" x 52" Spindles
7/8" x 1 1/2" x 51" Spindles
11
Keystones (base & locking top)
12
Hardware kit (2 bags):
1 1/2 oz. tubes of glue
2" x 3 1/2" Mounting brackets
3/4" Stainless screws
4" Stainless screws
Cap/washer assembly
Materials (Optional):
- 5" sq. treated wood posts.
- Pre-mix concrete
stability, especially when attaching a gate).
or 120"
Posts
(Std)
(Pro)
(tan model only)
(recommend for added strength &
Yorkshire Arbor
Assembly & Mounting Instructions
General Information:
- Read instructions through carefully before
beginning assembly.
- Identify each component from material list.
- When assembling components, place on a
non-abrasive surface to avoid scratches.
- Do not use excessive force when assembling
components.
- In the event of missing or defective parts,
please call our customer service department
at 1-800-282-9346 (ext.#20).
Tools Required:
Quantity
- Cordless drill & #2 Robertson bit
- Tape measure
4
- Level
2
- Shovel
4
4
Part 2
20
2
4
2
10
4
4
95 1/2"
4
2
2
1
2
24
10
26
49"
Opening
(Fig. 2)
Post layout for installation.
Part 3
Part 5
84"
Part 4
Part 11
Part 8
87 1/2"
Part 7
Part 1
49"
Part 10
Part 6
59"
(Fig. 1)
Product dimensions & part
identification.
32"
(Fig. 3)
Cap/washer assembly.
Ver 1.07
Part 9
58 1/2"
42"
Advertisement
Related Manuals for New England Arbors Yorkshire
Summary of Contents for New England Arbors Yorkshire
- Page 1 Yorkshire Arbor Assembly & Mounting Instructions General Information: - Read instructions through carefully before beginning assembly. - Identify each component from material list. - When assembling components, place on a non-abrasive surface to avoid scratches. - Do not use excessive force when assembling components.
- Page 2 To attach the bottom rail bracket to the post, measure a distance of 32 1/2” starting from the bottom hole and stretching down towards the bottom of the post. Place the open end of the bracket at the 32 1/2” mark and fasten into place (with the open end facing up). Repeat this step on each post.
- Page 3 Place the filter onto the guide pins. Push down firmly until it “snaps” in place and apply pressure for a few seconds to allow the glue to bond. Take one 4” screw and fasten each end of the filter through the top of the arch, making sure not to hit the pins below.
- Page 4 Slide each trim cap up to the underside of the arch, and press the cap firmly against the flat of the arch. Hold for a few seconds to allow the glue to bond. Using four 3/4” screws per post, fasten through the post &...
