College Park ODYSSEY K2 Technical Instructions

GAIT MATCHING GUIDELINES
®
After completing the alignment, if the foot feels too soft/too firm, verify that the foot has been built
correctly for the user's body weight
0-140
LBS
IMPACT LEVEL 0-63
KG
LOW SOFT
Contact College Park Technical Service if you have questions about modifying the gait match.
WARNING
Do not expose this product to corrosive materials, salt water or pH extremes.
■
Contaminants such as dirt and the use of lubricants or powder may effect the function of the CPI Sock
■
and lead to noise.
Failure to follow these technical instructions or use of this product outside the scope of its Limited
■
Warranty may result in injury to the patient or damage to the product.
WARRANTY INSPECTION AND MAINTENANCE INFORMATION
College Park recommends that you schedule your patients for check-ups according to the
warranty inspection schedule below.
High patient weight and/or impact level may require more frequent inspections. We recommend you
visually inspect the following applicable parts for excessive wear and fatigue at each warranty inspection.
• Hydraulic Assembly
Composites and Adapters
•
CPI Sock
•
Foot Shell
•
WARRANTY INSPECTION SCHEDULE FOR ODYSSEY
Technical Assistance / Emergency Service 24-7-365
College Park's regular office hours are Monday thru Friday, 8:30
emergency Technical Service number is available to contact a College Park representative.
800.728.7950 | 586.294.7950 | college-park.com
COLLEGE PARK INDUSTRIES
27955 College Park Dr. Warren, MI 48088 USA
©2015 College Park Industries, Inc. All rights reserved. College Park and Gait Matching are registered trademarks, with Odyssey
and FootHorn as trademarks of College Park Industries, Inc. US Patent number 8,926,711.
21-30 CM 25-30 CM
141-180 181-220 221-300
LBS LBS
64-81 82-100 101-136
KG KG
MEDIUM FIRM X-FIRM
: 6 MONTHS, THEN ANNUALLY.
K2
– 5:30 (EST). After hours, an
am pm
MADE IN THE USA
430 INS OK2 TIS 150330
EMERGO EUROPE
Molenstraat 15, 2513 BH, The Hague, Netherlands
TECHNIC AL INS TRUC TIONS
LBS
KG
PACKAGE CONTENTS
(1) Odyssey
(1) Foot Shell
(1) CPI Sock
k2
F E A T U R IN G :
• P at en te d cu rv
h yd ra u lic cy lin d
• In te lli W ea ve ™
co m p o si te fo o t
• D u al st ag ed
TOOLS RECOMMENDED
Foot 3mm Hex Key
K2
4mm Hex Key
FootHorn™
ed
er
b as e
st ri d e co n tr o l
