LGFK0016
PAGE 1 OF 9
FITTING INSTRUCTIONS FOR LGFK0016 MOULDED LEVER GUARD FITTING KIT
YAMAHA YZF-R6 2006—2016
.
THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE
.
SOME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY
.
DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT
.
PLEASE READ ALL INSTRUCTIONS BEFORE PROCEEDING
IF IN ANY DOUBT WHEN FITTING OUR PRODUCTS, CONSULT ONE OF OUR DEALERS
OR HAVE FITTED BY A QUALIFIED TECHNICIAN.
PLEASE NOTE THAT THE WAY THE KIT IS PACKED DOES NOT NECESSARILY REPRESENT THE WAY OF
.
MOUNTING TO THE BIKE
,
IN THE EVENT OF RUBBER WASHERS BEING USED TO HOLD COMPONENTS ONTO BOLTS
.
THESE RUBBER WASHERS CAN BE THROWN AWAY
DIGITAL COPIES OF THESE INSTRUCTIONS ARE AVAILABLE FROM:
WWW.RG-RACING.COM
R&G Racing
Unit 1, Shelleys Lane, East Worldham, Alton, Hampshire GU34 3AQ.
Tel: +44 (0)1420 89007 Fax +44 (0)1420 87301
www.rg-racing.com
Email:
info@rg-racing.com
Advertisement
Table of Contents
Related Manuals for R&G LGFK0016
Summary of Contents for R&G LGFK0016
- Page 1 LGFK0016 PAGE 1 OF 9 FITTING INSTRUCTIONS FOR LGFK0016 MOULDED LEVER GUARD FITTING KIT YAMAHA YZF-R6 2006—2016 THIS KIT CONTAINS THE ITEMS PICTURED AND LABELLED OVER PAGE SOME PARTS MAY BE SHOWN FOR CLARITY OF INSTRUCTIONS ONLY DO NOT PROCEED UNTIL YOU ARE SURE ALL PARTS ARE PRESENT...
-
Page 2: Tools Required
LGFK0016 PAGE 2 OF 9 TOOLS REQUIRED GENERAL TORQUE SETTINGS • 4mm A/F Allen Tool M4 BOLT = 8Nm M5 BOLT = M6 BOLT = M8 BOLT = 20Nm 0 BOLT = 40Nm M12 BOLT = 40Nm LEGEND ITEM DESCRIPTION... -
Page 3: Fitting Instructions
LGFK0016 PAGE 3 OF 9 FITTING INSTRUCTIONS • Begin by removing the OEM bar-end. • Referring to the assembly diagram found on page 2. Place the M6 countersunk bolt (item 5) through the countersunk spacer (item 3). • Place the carbon lever guard (item 1) over the exposed thread followed by the cone spacer (item 4) so the spacer sits inside the lever guard. - Page 4 LGFK0016 PAGE 4 OF 9 NOTICE DE MONTAGE LGFK0016 KIT DE PROTECTION POIGNEE MOULEE YAMAHA YZF-R6 2006—2016 E KIT CONTIENT LES ARTICLES EN PHOTO ET ETIQUETTES SUR LA PAGE LES PARTIES PRESENTÉES PEUVENT ETRE UNIQUEMENT REPRESENTATIVES POUR LA CLARTE DES INSTRUCTIONS E PAS ROCÉDER AU MONTAGE AVANT DE VOUS ÊTRES ASSURE QUE TOUTES LES PIECES SOIENT PRÉSENTES...
-
Page 5: Outils Requis
LGFK0016 PAGE 5 OF 9 OUTILS REQUIS VALEURS DE SERRAGE • Clé Allen 4mm M4 BOULON = 8Nm M5 BOULON = M6 BOULON = M8 BOULON = 20Nm 0 BOULON = 40Nm M12 BOULON = 40Nm LEGENDE ARTICLE DESCRIPTION ARTICLE 1... -
Page 6: Notice De Montage
LGFK0016 PAGE 6 OF 9 NOTICE DE MONTAGE • Retirez l’embout de guidon d’origine. • En vous référant au schéma de montage de la page 2. Placez le boulon à tête fraisée M6 (article 5) à travers l'entretoise à tête fraisée (article 3). - Page 7 LGFK0016 PAGE 7 OF 9 MONTAGEANLEITUNG FÜR LGFK0016 BREMSHEBELSCHUTZ YAMAHA YZF-R6 2006—2016 EILE SIND AUF DEN NÄCHSTEN EITEN ABGEBILDET UND GEKENNZEICHNET IE ABGEBILDETEN EILE DIENEN LEDIGLICH ZUR RKLÄRUNG Ü BERPRÜFEN IE ZUERST DASS ALLE EILE VORHANDEN SIND ESEN IE DIE...
- Page 8 LGFK0016 PAGE 8 OF 9 SIE BENÖTIGEN FOLGENDES WERKZEUG: ALLGEM. ANZUGSDREHMOMENTE M4 SCHRAUBE = 8Nm • 4mm A/F Inbusschlüssel M5 SCHRAUBE = 12Nm M6 SCHRAUBE = 15Nm M8 SCHRAUBE = 20Nm M10 SCHRAUBE = 40Nm M12 SCHRAUBE = 40Nm LIEFERUMFANG...
- Page 9 LGFK0016 PAGE 9 OF 9 MONTAGEANLEITUNG • Fangen Sie an, indem Sie das original Lenkerende entfernen. • Entsprechend der Zeichnung auf Seite 2, die M6 Senkschraube (Artikel 5) in den Distanzhalter (Artikel 3) einführen. • Den Bremshebelschutz aus Carbon (Artikel 1), gefolgt vom konusförmigen Distanzhalter (Artikel 4) über das hervorstehende Gewinde schieben, so dass der Distanzhalter im Inneren des...
