NAF ProCap Capping Valve User Instruction – FCD NFENIM4155-00-A4 11/18
• When lifting the valve package, be aware of its weight and high centre
of gravity! Please read instructions under 2.2 "Lifting"
• If the valve has been delivered with the Pressure Safety Switch Unit
option, please make sure to follow the instructions in Section 5.2 in order to
make sure the Pressure Switches are connected to the digester pressure
and that the flushing valves are locked in the closed position during normal
operation!
• The product must not be operated beyond the parameters specified for
the capping valve. If there is any doubt as to the suitability of the capping
valve, contact Flowserve NAF for advice.
• Installing, operating, or maintaining the product/system in any way that is
not covered in this User Instruction could cause death, serious personal
injury, or damage to the equipment. This includes any modification to the
product/system or use of the parts not provided by Flowserve.
• Only operate the product/system when it has successful passed all
inspection acceptance criteria
• Do not operate the product/system in a partially assembled condition.

3 Receiving Inspection

All ProCap valves leaving our facility are inspected and tested in accordance with the
relevant requirements. Valves equipped with actuators are subjected to functional
testing and are adjusted in such a manner that every unit is ready for direct installation
to the digester. However, NAF always recommend that a receiving inspection is to be
carried out.
We suggest the following inspection procedure:
• Check that the valve delivered is correct in terms of type, size, equipment,
etc.
• Examine the valve, actuator and valve accessories for possible damage
that may have occurred during transport.

4 Lifting and handling

When lifting the valve package, be aware of its weight and high centre of gravity!
All lifting must be carried out on the valve itself and not on the actuators, limit switches
or other accessories. The valve has a high centre of gravity and may rotate if the valve
is only lifted in the valve body necks. We recommend that the valve is lifted using a
minimum of 3 pcs high strenght lifting eye bolts. In order to better balance the valve to
an upright position, please use one lifting point around the upper valve body neck (near
