- Page 1 Argus Ball valves Service Manual Types: EK/71 EK/74 FK/75 FK/76 FK79 FK/79/F FK/492 HK/35 MW/22 Experience In Motion 三千控制阀网 www.cv3000.com...
-
Page 2: Table Of Contents
Argus Table of contents Disassembly ..............13 Table of contents Exchanging the Stem Sealing .......... 13 Type FK/78................14 Designed Use ............3 Disassembly ..............14 Application Areas..............3 Exchanging the Stem Sealing .......... 14 Design ...................3 Reassembly ..............14 Installation ................3 Type FK/79................ -
Page 3: Designed Use
Argus Designed Use Maintenance Designed Use Ball valves are maintenance-free. It is advisable, however, to actuate them at least once or twice a year. Series EK, FK and HK ball valves are used as shut-off devices in pipelines associated with processing, Safety Information handling and transporting liquid or gaseous as well as solid materials. - Page 4 Argus Safety Information Danger! Caution! De-pressurize the ball valve by turning the ball at 90° before removing drain and ventilation plug Use temperature measuring strips to check that the temperature does not rise beyond the (see Chapter Drain Plug). permissible limits (100°C). The strips must be fitted to the connection near the soft inserts (see Chapter Installing the Welding Connection).
-
Page 5: Safety Standards
Argus Safety Standards Safety Standards Delivery/Storage Depending on the type and pressure rating, ARGUS ball valves are designed to conform with national and Check on Delivery international regulations, such as DIN 3357, AD and VdTÜV-Merkblätter, TRbF, TRGL, TRD, TRG, DVGW, BS 5351, API6D and ANSI B16.34. -
Page 6: Transport
Argus Transport Transport Danger! Local safety regulations must be complied with for transport to the place of installation. Make sure that the valves cannot tilt or slip in any way (see figure below). 0000-00-002 The user is liable for any damage resulting from incorrect transport. 三千控制阀网... -
Page 7: Installing The Flanged Connection
Argus Installing the Flanged Connection Installing the Flanged Connection Installing the Ball Valve Transport the ball valve safely to the installation site using suitable hoisting gear dimensioned in accordance with the weight and size of the ball valve (Figure 0003-00-002). Remove protective caps (Figure 0003-00-004). -
Page 8: Installing The Welding Connection
Argus Installing the Welding Connection Installing the Welding Connection Danger! The local welding regulations and specifications must be complied with when carrying out welding Installing the Ball Valve work. Transport the ball valve to the installation site using suitable hoisting gear dimensioned in accordance with the weight and size of the ball valve (Figure 0002-00-002). -
Page 9: Start-Up
Argus Start-up Start-up 0001-00-001 0001-00-002 0001-00-003 Warning! Before start-up of the ball valve a leak test must be performed. Before start-up of the ball valve, the pipe-line must be tested under pressure, rinse and dried. Warning! The ball valve must be set to the OPEN position in order to avoid any damage. The flange connections must be checked again after rinsing. -
Page 10: Maintenance
Argus Maintenance Maintenance Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible Type EK/71 pressure behind the ball may escape. Disassembly Stem (22) should be in CLOSED position. Remove snap ring (12) and stop disk (7). Detach screws (8, 9) with bush (5). -
Page 11: Type Fk/74
Argus Maintenance Type FK/74 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Stem (31) should be in CLOSED position. Remove thrust ring (22) and stop disk (10). Detach hexagon nut (15) with ring (16). -
Page 12: Type Fk/75
Argus Maintenance Type FK/75 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Stem (31) should be in CLOSED position. Remove snap ring (22) and stop disk (10). Unscrew hexagon screws (15). -
Page 13: Type Fk/76
Argus Maintenance Type FK/76 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Stem (31) should be in CLOSED position. Remove snap ring (22) and stop disk (10). Unscrew hexagon screws (15). -
Page 14: Type Fk/78
Argus Maintenance Type FK/78 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Stem (31) should be in CLOSED position (visible notch crosswise the direction of flow). Remove snap ring (22). -
Page 15: Type Fk/79
Argus Maintenance Type FK/79 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Stem (22) should be in CLOSED position. Remove snap ring (12) and stop ring (7). Unscrew cheese-head screws (8). Take off plate (6) with sealing ring (43) and bush (36) on DN 20 and 25 or bearing tape (34) and dowel ∗∗... -
Page 16: Type Fk/79/F
Argus Maintenance Type FK/79/F Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. TYP / TYPE / TYPE FK/79/F Disassembly Stem (31) should be in CLOSED position. Remove snap ring (22) and stop ring (10). Unscrew cheese-head screws (15). -
Page 17: Type Fk/492
Argus Maintenance Type FK/492 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Stem (5) should be in CLOSED position. Unscrew hexagonal nuts (11) from body (2). Take off body (2) and seal (9) from body (1), remove ball (4) and sealing rings (3). -
Page 18: Type Hk/35
Argus Maintenance Type HK/35 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Stem (22) should be in CLOSED position. Remove snap ring (12), stop ring (7), snap ring (18) and washer (19). Unscrew cheese-head screws (8). -
Page 19: Type Mw/22
Argus Maintenance Type MW/22 Danger! Do not disassemble the valve under pressure. Before disassembly operate valve so that possible pressure behind the ball may escape. Disassembly Unscrew the connection pieces (13) with O-rings (33), annular pistons (34) and Belleville washers (11) from body (1). -
Page 20: Accessories
Argus Accessories Accessories Stuffing Box Assembly Re-tensioning the Seal The stuffing box seal can be re-tensioned if necessary. For this purpose, turn the nuts on the head-less pins clockwise to retighten them (Figure 0104-00-001). Caution! Do not loosen the fixing nuts (Figure 0104-03-001). Changing the Seals Danger! The ball valve must be depressurized! To release pressure, turn ball. -
Page 21: Drain Plug
Argus Accessories Drain Plug Drain and Ventilation Safety Plug The safety plug is a special-purpose design to prevent the drain and ventilation plug from accidentally being lost. In addition, it allows the drain and ventilation plugs to be closed immediately if the ball valve is still accidentally pressurized (Figure 0105-00-002). -
Page 22: Supplementary Equipment
