- Page 1 Sopwith Camel Assembly Instruction Precautions: ·When using foam glue, apply the glue to the bonding surface, dry for 1-2 minutes before bounding the parts. ·When parts are difficult to remove, use tool to cut it out.
- Page 2 Part distribution...
- Page 4 2. Apply cockpit interior stickers...
- Page 5 3. Pre-bend the skin before installation and check the position match.
- Page 7 6. Pre-bend the skin before installation and check the position match.
- Page 8 9. Pre-bend the skin before installation and check the position match.
- Page 12 16. Bend the bottom of the wing support at a width of 3mm.
- Page 13 17. Paste the cockpit exterior sticker before installing the wing support.
- Page 14 20. Paste horizontal tail reinforcement.
- Page 15 21． 22. Carve a crease at a distance of 20 mm from the leading edge of the wing...
- Page 16 23. Paste wing reinforcement sticker...
- Page 17 24. Install the ribs. Please note: there are no ribs on the outermost side of the wing.
- Page 18 25.The side of the fuselage has an indentation corresponding to the wing installation position.
- Page 25 39. Use a straw to make a machine gun. The side of the straw is cut open, adjusted to a diameter of 4.5mm, covered with sticker.
- Page 27 ·Adjust the center of gravity to the upper wing support beam ·The rudder surface neutral point is adjusted to the same level of the tail · Elevator and rudder amount are 5-8mm on both sides ·Enjoy your flight. Contact MinimumRC: oceanchueng@qq.com...
