  • Page 1 MODEL BETA-M 2 of 2...
  • Page 2 Versions Firmware 2.00 Programming parameters lockout or later See page 71 Compatible Modbus Back to Factory Configuration See page 86 See page 65 Fail Safe Function Linearization by segments See page 108 See page 36 Sensor Break Alarm 3 Tare Modes See page 107 See page 105 36 Logical Functions...
  • Page 3 DIGITAL PANEL INSTRUMENT BETA FAMILY MODEL BETA-M Index 1 - Beta-M model overview ............................6 - 7 1.1 Mode RUN: front-panel description ........................8 1.2 Mode PROG: front-panel description ........................9 2 - Getting started ................................10 2.1 Power and connectors ..........................11 - 12 2.2 Programming instructions ..........................
  • Page 4 DIGITAL PANEL INSTRUMENT BETA FAMILY MODEL BETA-M 4 - Programming module 20. Display configuration diagram ..................34 - 35 4.1 Scaling. Menus 21 and 22 ..........................36 - 45 4.2 Integrator. Menu 23 ............................ 46 - 48 4.3 Display options, Filters and Round ........................49 4.3.1 Display options.

  • Page 5: Enter Key

    MAX/MIN key TO RESET PEAK, VALLEY, TOTAL or BATCH : Recalls the following parameters to the second display : first RESET key push recalls peak, second push recalls valley, third push Press until desired parameter appears on the second MAX/MIN recalls tare (or offset).
  • Page 6 5.2 - Logic Functions The rear connector CN2 provides 4 user programmable opto-coupled inputs that can be operated from external contacts or logic levels supplied by an electronic system. Four different functions may be added to the functions available from the front- panel keys.
  • Page 7 5.2.1 - Table of programmable functions Definition of the column "Action" Edge : The function is active when a negative edge is applied to the corresponding pin referred to common. Level : The function is active as long as the corresponding pin is held at a low level with respect to common. (*) Factory configuration.
  • Page 8 13 to 16 : FUNCTIONS ASSOCIATED TO THE ANALOG OUTPUT Nº Name Function Action ANA GROSS The analog output follows the gross value (measured value + tare). Level ANA ZERO Puts the analog output to the zero state (0V or 4mA) Level ANA PEAK The analog output follows the peak value...
  • Page 9 26 to 36 : SPECIAL FUNCTIONS (cont.) Nº Name Function Action ASCII Send the display last four digits to a Micra-S indicator Edge SETS INHIBIT Suspends setpoint operations and keeps the outputs to their OFF state Level BATCH Adds the current display value to the totalizer and increments the batch Edge counter in one unit.
  • Page 10 5.2.2 - Program the logic functions Press to enter in the programming mode (-Pro- level) and press repeatedly ENTER until the indication shown in figure 70.1 appears on the display. From this stage press to access the logic inputs configuration. The key rotates ENTER HOLD...
  • Page 11 6. PARAMETER LOCKOUTS The instrument is supplied with all software programming TOTAL LOCKOUT parameters accessible to operator's modifications. After The access to the programming routines to read data is completing the software configuration, it is recommended to allowed even if all parameters are locked out, but it won’t take the following steps: be possible to enter or modify data.
  • Page 12 6.1 - Lockout programming routine 88888 The lock-out programming routine is entered by depressing SEt1 key for 3 seconds and introducing a security code. ENTER This gives access to either the parameter list or to change the code if desired. SEt2 - - - - If the user opts for changing the code, the unit asks for the...

  • Page 13: Output Options

    7. OUTPUT OPTIONS The options are supplied with a specific instructions manual Output options with instructions manual edited before describing characteristics, installation, connections December 1999, work properly with new versions of programming. The output cards are easily installed on the Beta-M but some new features may not be described in meter's main board by means of plug-in connectors and each the options manual.
  • Page 14 The figure shows the main circuit board locations of the available output options. Each plug-in location can accept only one card from a particular function type. The options 2RE, 4RE, 4OP and 4OPP are for setpoint control and only one of them can be installed in the M5 location.

  • Page 15: Input Signal

    8. TECHNICAL SPECIFICATIONS INPUT SIGNAL Temperature input • Cold junction compensation ....-10 ºC to +60 ºC • Configuration ......differential asymmetrical • Cold junction ......±(0.05 ºC/ ºC +0.1 ºC) • Pt100 excitation current ........ < 1 mA DC Process input Voltage Current...
  • Page 16 ELECTRICAL SAFETY ENVIRONMENTAL • Installation category ..........II (indoor use) • Degree of pollution ............ 2 • Operating temperature ....... -10 ºC to +60 ºC • Storage temperature ......-25 ºC to +85 ºC FUSES (DIN 41661) - Not supplied •...

  • Page 17: Sealing Gasket

    8.1 - Dimensions and mounting To mount the instrument into the panel, make a cutout of FIXING CLIPS SEALING GASKET 92x45mm. Slide the sealing gasket over the instrument's case to the bezel and insert the instrument through the panel cutout from the front. PANEL CUTOUT 92 mm PANEL...
  • Page 18 All the DITEL products benefit from an unlimited and unconditional warranty of THREE (3) years from the date of their purchase. Now you can extend this period of warranty up to FIVE (5) years from the product commissioning, only by fulfilling the corresponding form.

  • Page 20: Declaration Of Conformity

    10. DECLARATION OF CONFORMITY Manufacturer : Applicable Standars : DITEL - Diseños y Tecnología S.A. EN50081-1 Generic emission EN55022/CISPR22 Class B Address : Applicable Standars : Polígono Industrial Les Guixeres EN50082-1 Generic immunity C/ Xarol 8 C IEC1000-4-2 Level 3...
  • Page 22 ANNEXES MODEL BETA-M Index SECTION Page ANNEXE A. SETPOINTS ANNEXE B. SERIAL OUTPUTS RS232C AND RS485 B.1. List of Commands 84 to 85 B.2. Address of the Variables in the memory 86 to 103 ANNEXE C. c1. TARE MODE 105 to 106 c2.
  • Page 23 ANNEXE A. SETPOINTS The option ‘MAX’ is for non-filtered peak values and the option ‘MAX-F’ is for filtered values. The setpoint configuration options (latch, HI-LO mode, delay-hysteresis, blink) The following functions have been added: are programmed as for a standard setpoint but some have different meanings in this case, the setpoint value is the display value from which the unit begins 1.
  • Page 24 ANNEXE B. SERIAL OUTPUT RS232C or RS485 B.1. List of Commands REQUEST OF DATA ASCII Information Logic inputs status Peak value Valley value Tare/Offset value Display value Totalizer value Batch counter value Value of the setpoint1 Value of the setpoint2 Value of the setpoint3 Value of the setpoint4 Bit 0=input overfow, bit 1= scale overflow, bit 2= Sensor break...
  • Page 25 COMMANDS ASCII MODBUS Command Reset latched outputs Reset peak Reset valley Reset tare Tare the display Reset totalizer Reset batch counter Activate setpoint1 Activate setpoint2 Activate setpoint3 Activate setpoint4 Deactivate setpoint1 Deactivate setpoint2 Deactivate setpoint3 Deactivate setpoint4...
  • Page 26 B.2. Address of the Variables in the Memory PROGRAMMING DATA (READ/WRITE) MODBUS Variable Description INPUT POINT 1 Sign 0=+,A=- digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 2 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 3 sign...
  • Page 27 INPUT POINT 6 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 7 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 8 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 9 sign...
  • Page 28 INPUT POINT 12 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 13 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 14 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 15 sign...
  • Page 29 INPUT POINT 18 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 19 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 20 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 21 sign...
  • Page 30 INPUT POINT 24 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 25 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 26 sign digit 4 digit 3 digit 2 digit 1 digit 0 INPUT POINT 27 sign...
  • Page 31 INPUT POINT 30 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 1 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 2 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 3 sign...
  • Page 32 DISPLAY POINT 6 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 7 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 8 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 9 sign...
  • Page 33 DISPLAY POINT 12 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 13 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 14 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 15 sign...
  • Page 34 DISPLAY POINT 18 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 19 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 20 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 21 sign...
  • Page 35 DISPLAY POINT 24 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 25 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 26 sign digit 4 digit 3 digit 2 digit 1 digit 0 DISPLAY POINT 27 sign...
  • Page 36 DISPLAY POINT 30 sign digit 4 digit 3 digit 2 digit 1 digit 0 SETPOINT 1 digit 7 / sign digit 6 digit 5 digit 4 digit 3 digit 2 digit 1 digit 0 SETPOINT 2 digit 7 / sign digit 6 digit 5 digit 4...
  • Page 37 digit 1 digit 0 DELAY / HYSTERESIS digit 4 SETPOINT 1 digit 3 digit 2 digit 1 digit 0 DELAY / HYSTERESIS digit 4 SETPOINT 2 digit 3 digit 2 digit 1 digit 0 DELAY / HYSTERESIS digit 4 SETPOINT 3 digit 3 digit 2 digit 1...
  • Page 38 DELAY-HYST SETPONT 3 0=delay, 1=hysteresis-1, 2=hysteresis-2 DELAY-HYST SETPONT 4 0=delay, 1=hysteresis-1, 2=hysteresis-2 LATCH SETPOINT 1 0=no, 1=yes LATCH SETPOINT 2 0=no, 1=yes LATCH SETPOINT 3 0=no, 1=yes LATCH SETPOINT 4 0=no, 1=yes BLINK SETPOINT 1 0=LED, 1=LED+blink BLINK SETPOINT 2 0=LED, 1=LED+blink BLINK SETPOINT 3 0=LED, 1=LED+blink...
  • Page 39 digit 1 digit 0 DIAMETER 2 (VOLUME) digit 4 digit 3 digit 2 digit 1 digit 0 LENGTH 2 (VOLUME) digit 4 digit 3 digit 2 digit 1 digit 0 DIAMETER 3 (VOLUME) digit 4 digit 3 digit 2 digit 1 digit 0 LENGTH 3 (VOLUME) digit 4...
  • Page 40 FILTER P 0 to 9 FILTER E 0 to 9 READINGS AVERAGE digit 2 digit 1 digit 0 BRIGHT 0=HI, 1=LO LEFT ZEROS 0=no, 1=yes RATE 0=16/s, 1=4/s, 2=1/s ROUND 0=001, 1=002, 2=005, 3=010, 4=020, 5=050, 6=100 PRINT DATE AND TIME 0=off, 1=on INTEGRATOR 0=no, 1=yes...
  • Page 41 SOFT LOCK 2 bit 0 = input bit 1 = scaling+integrator+volume bit 2 = filters+display+round bit 3 = - SOFT LOCK 3 bit 0 = analog output bit 1 = serial communication output bit 2 = logic inputs bit 3 = direct programming of setpoint values SOFT LOCK 4 bit 0 = tare key function bit 1 = -...
  • Page 42 DINAMIC VARIABLES (READ ONLY) MODBUS Variable Description Format Peak Value Internal peak value Long Valley value Internal valley value Long Tare value Internal tare value Long Batch counter Internal batch counter Integer (1 word) Totalizer Internal totalizer counter Float Net value Net value on display (with filters, round and hold) Long Gross value...
  • Page 43 MODBUS Variable Description Format Options installed bit 0 = 2RE Byte (0=not installed, 1=installed) bit 1 = 4RE bit 2 = RS2 bit 3 = RS4 bit 4 = - bit 5 = BCD bit 6 = ANA bit 7 = - Digits of the main display digit 0 (LSB) Byte...

  • Page 45: Tare Mode

    TARE MODE On tArE1 mode at one press of the key, the instrument stores the value shown on display at this TARE moment, if it is not on overflow, the TARE LED lights and from this moment the shown value is net value (the measured minus the stored).
  • Page 46 Programming: If have selected input Process or Potentiometer, on the menu 20 “CndSP” after submenu 27 “–VoL-“ and with another push of key you get the submenu ModTA. If have selected input “Load Cell” on the menu 20 “CndSP” after the submenu 26 and pushing key you get the submenu ModTA.

  • Page 47: Sensor Break

    SENSOR BREAK This function allows detecting any broken wire that connect the sensor “Load Cell” to the instrument. The analysis to detect the broken wires is done every 1,5 seconds and the response of Relays and ANA options (if used) will be the same if it were a overflow (oVFLo) situation, input signal greater than allowed.

  • Page 48: Setpoint Value

    FAIL SAFE Function that allows detecting the power supply fault or an instrument fault and in this way can be informed the PLC or another general system of supervision using the relay option programmed in this way. This function can be programmed on any of the activated relay, in the submenu 31, 32, 33, 34 after the programming parameter “–Hi-Lo-“...
  • Page 49 r.o.C. Function (rate of Change) The function r.o.C is useful to detect the changing speed of display value, depending on programmed setpoint polarity we detect the increasing or decreasing. In mode r.o.C., if the setpoint values is, for example = 1000, that means that the alarm will be activated when the display value increase more than 1000 points per second.
  • Page 50 doSE THERMOCOUPLE and Pt100 If has been programmed input “Load Cell, Potentiometer or Process”, only in the submenu 31 is possible to select the function “doSE” PEAK WAY of WORKING of SETPOINT1 in MODE "doSE" When the function “doSE” is selected on the setpoint 1 menu, can not choose the comparison value, since it will be on the net value of the display. Nor can choose HI or LO mode as this will depend on whether the setpoint is positive (HI) or negative (LO) and the numerical value of setpoint will have to be mandatory to program on the direct programming of setpoint values routine (keys ENTER and LIMIT).
  • Page 51 trAC MENU 34 trAC...
  • Page 52 DISEÑOS Y TECNOLOGIA, S.A. Polígono Industrial Les Guixeres C/ Xarol 8 C 08915 BADALONA-SPAIN Tel : +34 - 93 339 47 58 Fax : +34 - 93 490 31 45 E-mail : dtl@ditel.es www.ditel.es...
