- Page 1 User’s manual FLIR EST Thermal Screening FLIR Screen EST and FLIR Exx/T5xx-EST or FLIR Exx/T5xx/T8xx Distributed by: Sie haben Fragen oder wünschen eine Beratung? Angebotsanfrage unter 07121 / 51 50 50 oder über info@datatec.de...
-
Page 2: Table Of Contents
3.5.1 Examples — equipment and material........5 Supporting material ..............5 3.6.1 Examples — supporting material ........6 Screening with the FLIR Screen EST application ........7 Screening procedure ..............7 Screening station equipment ..............9 FLIR products ................9 5.1.1 FLIR Exx/T5xx-EST ............9 5.1.2... - Page 3 Table of contents 7.10 Place the supporting material ............ 18 Screening procedure — Operator instructions ........19 Keep the average value updated ..........19 #T810558; r. AC/68383/68383; en-US...
-
Page 4: Notice To User
Notice to user 1.1 Note about this manual This manual describes how to set up, configure, and operate a FLIR EST Thermal Screening station based on the FLIR Screen EST application and a FLIR Exx-EST, FLIR T5xx-EST, FLIR Exx, FLIR T5xx, or FLIR T8xx series camera. -
Page 5: Flir Est Thermal Screening Solutions
FLIR Systems provides different screening solutions for detection of elevated skin tem- peratures using thermal cameras. No thermal camera can detect or diagnose a virus or infection, but with a FLIR EST Ther- mal Screening Solution it is possible to identify individuals with skin temperatures that are above a specified threshold. -
Page 6: Screening Station - General Description
Screening station — General description 3.1 Overview The screening station typically consists of a FLIR thermal camera, a FLIR EST Thermal Screening application (e.g. desktop software or camera mode), a clearly defined screen- ing position, and a backdrop. For improved measurement accuracy, it is important that the screened person is at the correct distance from the camera. -
Page 7: Privacy And Processes
3.4 Privacy and processes FLIR EST Thermal Screening Solutions offer a wide variety of (default) settings and op- tions to allow you to use FLIR cameras in accordance with your needs and in compliance with any applicable laws and guidelines. -
Page 8: Examples - Equipment And Material
Screening station — General description 3.5.1 Examples — equipment and material Figure 3.2 Stand with rail for flexible mounting of Figure 3.3 Backdrop display and camera 3.6 Supporting material #T810558; r. AC/68383/68383; en-US... -
Page 9: Examples - Supporting Material
The floor sticker indicates the screening position; that is, where the persons should stand for the screening. 3.6.1 Examples — supporting material Figure 3.4 Roll-up, screening information Figure 3.5 Roll-up, screening instructions Figure 3.6 Floor sticker For available supporting material from FLIR Systems, go to https://www.flir.com/. #T810558; r. AC/68383/68383; en-US... -
Page 10: Screening With The Flir Screen Est Application
Screening with the FLIR Screen EST application FLIR Screen EST is an application for detection of elevated skin temperatures using ther- mal cameras. Using face-detection capabilities, the system determines an average skin temperature of people entering the camera field-of-view and automatically alarms on readings that ex- ceed a selected temperature difference. - Page 11 Screening with the FLIR Screen EST application 4. You are in a good position. The system is measuring and evaluating your temperature. 5. The screening is completed and your result is displayed. No elevated temperature detected. Elevated temperature detected. Follow the instructions from the staff.
-
Page 12: Screening Station Equipment
Screening station equipment This chapter describes the FLIR products, equipment, and material needed to set up a screening station with the FLIR Screen EST application and a FLIR Exx/T5xx-EST or a FLIR Exx/T5xx/T8xx camera. 5.1 FLIR products 5.1.1 FLIR Exx/T5xx-EST When using a FLIR Exx/T5xx-EST camera, the following FLIR products are needed: •... -
Page 13: Computer And Display
• Visitor display. • Optional: Operator display. • Display cable. • Power cables. 5.2.1 System requirements For the FLIR Screen EST application, the computer and display must fulfil the following system requirements: Operating system Microsoft Windows 10 (32-bit and 64-bit) Hardware requirements... -
Page 14: Quick Guide To The Camera
6.1 New camera If you have a new camera, do the following: 1. Charge the battery for 2 hours (FLIR Exx-EST and FLIR Exx) / 3 hours (FLIR T5xx- EST and FLIR T5xx/T8xx) using the stand-alone battery charger. 2. Push the battery into the battery compartment. -
Page 15: Setting Up The Screening Station
Setting up the screening station This chapter provides step-by-step instructions for how to set up a screening station with the FLIR Screen EST application and a FLIR Exx/T5xx-EST or FLIR Exx/T5xx/T8xx camera. Before starting the setup, please read the entire chapter. Make sure you have all the needed FLIR products, equipment, and material, see section 5 Screening station equipment. -
Page 16: Install The Flir Screen Est Application
6. Run the application from the Start menu or by double-clicking the desktop icon. 7. The FLIR Screen EST dialog box appears where you can activate your license key. Note To complete the installation, the computer may need to be restarted. Follow the instructions on the screen. -
Page 17: User Interface
The size and position of the region-of-interest can be changed on the Live page. 7.5.4 User manual To access the FLIR Screen EST user manual, click User manual on the Library page or go to https://support.flir.com/screenest. 7.6 Place the camera, display, computer, and backdrop Figure 7.1 Typical screening station setup... -
Page 18: Height Of Screened Persons
Tilt the camera so that it aims at the face of the person. 6.3. Look at the live visual image in FLIR Screen EST and adjust the angle of the camera until the face of the person is inside the box. -
Page 19: Get Familiar With The Screening
You access the Settings page via the toolbar on the Library and Live pages in the opera- tor window. For most settings in the FLIR Screen EST application, it is recommended to use the de- fault settings. The settings that you may want to change are on the Face detection and General tabs on the Settings page. -
Page 20: Ensure Correct Setup
Setting up the screening station Alarm • Select the Log alarms to output folder check box to automatically save an image and a data file (*.csv) when the system detects an elevated temperature. By default, this check box is cleared and no images are saved automatically. •... - Page 21 4.3. Once the focus is correctly adjusted, make sure the focus is not changed. 5. Make sure the backdrop is correctly placed. Look at the live image in FLIR Screen EST and make sure the camera only sees the backdrop.
- Page 22 3. Turn on the camera. 4. In the Discovery pane in the FLIR Screen EST operator window, click the button to the right to connect to the camera. 5. For accurate temperature measurements, it is important that the camera focus is cor- rect.
- Page 23 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Distributed by: Sie haben Fragen oder wünschen eine Beratung? Angebotsanfrage unter 07121 / 51 50 50 oder über info@datatec.de...
