Installing the
IntelliJack
Component Purpose
Local power For locally powering a single IntelliJack;
supply required if your network does not support
Power Over Ethernet.
VoIP telephone For powering a VoIP telephone on a network
power cable that uses Capacitive Power Discovery
Process-compatible Power Over Ethernet.
Extension ring For ensuring that the IntelliJack is properly
mounted to a cubicle; required if the cubicle
opening:
n
n
n
Installing the IntelliJack consists of the following steps:
1 Set up the power supply (page 6).
2 Install the adapter plate and pass-through ports (page 8).
3 Plan the installation (page 9).
4 Set up the network cabling at your site (page 10).
5 Connect the IntelliJack to the network (page 10).
6 Mount the IntelliJack to the wall or office cubicle (page 11).
7 Connect the local power supply (page 12; optional) not required if your network
supports Power Over Ethernet or if you are using a single-port or multi-port power
supply).
8 Connect network devices to the IntelliJack (page 13).
Has a depth of fewer than 1.5 inches.
Does not support the NEMA-WD6
standard.
Does not have pre-drilled screw holes for
standard mounting.

Installing the IntelliJack

3C Number(s)
3CNJPSL
3CNJVOIPMOD-NBX
3CNJVOIPMOD-20
3CNJVOIP-CPOD
3CNJVOIP-CPOD-20
3CNJEXTRING
