Before You Begin; Obtaining Optional Components - 3Com IntelliJack NJ220 User Manual

4 C 1: I
HAPTER NSTALLING THE

Before You Begin

Obtaining Optional
Components
NJ220 I J
NTELLI ACK
Before you begin installation, register your product at:
http://eSupport.3com.com/.
The IntelliJack is available in single- and 20-packs. Before you begin the
installation, make sure you have the following items, which are included with the
IntelliJack:
• 1.5 inch, 6x32 screws (2 per IntelliJack) for mounting the IntelliJack to the wall
or office cubicle.
• Male to male RJ-45 coupler cable (1 per IntelliJack) for connecting the Ethernet
cable from the network to the IntelliJack (required only if your network cable is
terminated with a female RJ-45 connector).
Additionally, the following items are shipped with the single pack:
• Compact disc with User Guide and Configuration Manager software.
• Adapter plates for installing connectors to use as pass-through ports. The
adapter plates accommodate connectors from suppliers including:
Panduit (RJ-45 and RJ-11)
n
Avaya (RJ-45 and RJ-11)
n
• Adapter plate screws (2) for mounting the adapter plate to the IntelliJack.
NOTE: The connectors for the adapter plates must be purchased from the
manufacturer. For a list of supported connectors, go to the IntelliJack section of
www.3com.com/.
The IntelliJack works with the following optional components, all of which are
available from 3Com. Order online at www.3com.com or by calling
1-877-949-3266.
Component Purpose
Adapter plates For installing pass-through port connectors of
your choice that allow a direct connection to
another network segment or for connecting an
analog or digital PBX telephone. Available
adapter plates accommodate connectors for
the following manufacturers: AMP, Avaya,
Hubbell, Ortronics, and Panduit.
Single-port For providing Power Over Ethernet to locally
Ethernet power power a single IntelliJack.
supply
Multi-port For providing Power Over Ethernet to power
Ethernet power up to 24 IntelliJacks.
supply
3C Number(s)
3CNJAP-PA-20
3CNJAPB-PA-20
3CNJAP-AV-20
3CNJAPB-AV-20
3CNJAP-AM-20
3CNJAPB-AM-20
3CNJAP-HU-20
3CNJAPB-HU-20
3CNJAP-OR-20
3CNJAPB-OR-20
3CNJPSE
3CNJPSE24
3C17205
