Amino Kamai 750E User Manual

Kamai 750E
User Guide

Contents

The Kamai 750E is supplied with the correct power adapter for
your local system. The package may also contain optional
accessories shown below, depending on your service provider.
The product is protected with a clear plastic film. This should be
removed before use.

Optional accessories

HDMI cable
serial cable
Remote control
and batteries
1. Overview of the Kamai 7 E
1. Power/Activity LED:
Blue = on.
Blue flashing = IR command received / Kamai 7E starting
up.
Red = standby.
1. IR extender input.
2. HDMI output.
3. 2 x USB 3.0 ports.
4. Ethernet port (PoE+ to IEEE 802.3at - 2012).
5. DC power input 12 V 2 A.
6. Serial port.
7. Reset button. This has no function in normal use: only use
under guidance from your service provider.
50

Important - Safety instructions

Read these instructions carefully and keep for future reference. Note all
warnings.
The product contains no user-serviceable parts. Refer all servicing to qualified
service personnel.
Handle the product with care and do not attempt to dismantle the product.
Do not expose the product or its accessories to any liquids, rain or moisture.
Do not locate the product near a heat source and do not block ventilation
holes: the product will become warm during operation. Allow at least 10cm
(4") around the product for air circulation.
Do not locate the product where it may be subject to physical shock, vibration
or where the product may fall over.
Do not place the product on soft furnishings or carpets.
Only use the power supply provided by the manufacturer. The use of any
other type of power supply may invalidate any approval or warranty applying
to the product and may be dangerous. If the power supply does not match
your local system, contact your product supplier.
Protect the power supply cord from damage.
The disconnect device is the power supply cord. Removing the power supply
cord from the mains supply isolates the product from the mains.
Disconnect the product from the mains supply if left unused for long periods
of time or during electrical storms.
Disconnect the product before cleaning, and use a dry cloth only.
Only use attachments and accessories specified by the manufacturer.
The product is for indoor use only.
2. Connecting the Kamai 7 E to a TV
Warning! Before connecting or disconnecting any cable switch
off all system devices (TV, AV amplifier, etc.) and disconnect the
devices from the mains electrical supply.
Connect an HDMI cable to the HDMI output of the Kamai 750E
and to the HDMI input of the TV.

3. Connecting the power source

The Kamai 750E must only be used with the
Warning!
supplied power adapter.
For mains power: connect the power adapter to the DC
power input, then connect the power adapter to the mains
supply. The power adapter provided will be specific to your
region. Ensure you have the correct power adapter for your
region. If you are unsure, contact your service provider.
For PoE: Connect an Ethernet cable to the Ethernet port. This
will provide both data and power to the Kamai 750E.
