Table 7 Console Port Pinouts
Pin
1
2
3
4
5
6
7
8
9
Table 8 lists 9-pin-to-9-pin assignments for connecting your PC to the SFMM.
Table 8 RS-232 9-Pin-to-9-Pin Cable Connection Pin Assignments
Signal
CD
RX
TX
DTR
GND
DSR
RTS
CTS
Reserved
Table 9 lists 9-pin-to-25-pin assignments for connecting your PC to the SFMM.
Table 9 RS-232 9-Pin-to-25-Pin Cable Connection Pin Assignments
Signal
CD
RD
TD
DTR
GND
DSR
RTS
CTS
Reserved
High Availability To establish a redundant switch management configuration, you must have two
Operation Switch Fabric Management Modules (SFMMs) installed in the chassis. The slots for
management modules are M1 and M2.
A redundant SFMM configuration provides a seamless flow of management
operation. After the failover mechanism reboots the system, there is no loss of
configuration data.
Switch Fabric Management Module Overview
Signal Name
Not Used
Receive Data (RD)
Transmit Data (TD)
Not Used
Signal Ground (GND)
Not Used
Request to Send (RTS)
Clear to Send (CTS)
reserved
SFMM Pin DTE Pin
1 N/A
2 3
3 2
4 6
5 5
6 4
7 8
8 7
9 N/A
SFMM Pin DTE Pin
1 N/A
2 2
3 3
4 6
5 7
6 20
7 5
8 4
9 N/A
Signal
Not Used
TX
RX
Not Used
GND
Not Used
CTS
RTS
Not Used
Signal
Not Used
TD
RD
Not Used
GND
Not Used
CTS
RTS
Not Used
