Label NEPTIS SMP Installation Manual page 5

1) MODEL DESCRIPTION
The Neptis SMP operator has an electro-mechanical motor for opening the pedestrian swing doors.
The electronic control equipment is located inside the operator.
A list of the operator models for Neptis SMP swinging doors produced by Label is provided below:
The Neptis SMP operator can be used with a slide pull arm or with an articulated push arm.
The operator must be installed in indoor environments.
All models are reversible, therefore in the case of a power failure the door can be opened manually.
Before starting with assembly check the technical drawings in paragraph 5. A drawing of the application is provided for every type of
arm, with the installation dimensions and a chart that provides the weight limits based on the length of the door leaf.
The technical data provided in the charts refers to a typical installation, but the data can be influenced by variables present in every
system, such as friction, environmental conditions, alignment of the leaf hinge, etc....
2) TECHNICAL SPECIFICATIONS
POWER SUPPLY
POWER
POWER SUPPLY OF EXTERNAL ACCESSORIES
ELECTRIC MOTOR
OPERATOR WITH BATTERY DIMENSIONS (LxHxD)
WEIGHT
PROTECTION DEGREE
AMBIENT TEMPERATURE
FREQUENCY OF USE
LIMIT SWITCH AND ANTICRUSHING SAFETY
REACTION TO OBSTACLES
OPENING TIME for 95°
CLOSING TIME for 95°
PAUSE TIME
REFERENCE VALUES FORCE
MANUAL CLOSING TORQUE (Nm)
AUTOMATIC CLOSING TORQUE (Nm)
MANUAL TORQUE TO OPEN (Nm)
AUTOMATIC OPENING TORQUE (Nm)
115/230Vac +/-10%, 50-60Hz
120W
24Vdc, 1A
24Vdc
730 x 110 x 120 mm
10,8 Kg.
IP31
-15°C +50°C
continuous
encoder controlled
reversal of direction
4 - 12 seconds adjustable
5 - 15 seconds adjustable
0 - 20 seconds adjustable
NEPTIS SMP
ARTICOULATED ARM SLIDING ARM
Min Max Min
18 18 15
72 144 60
18 15
18
114 144 95
5
Max
15
120
15
120
