Blue Clean Take-Along Assembly, Care And Use Instructions page 7

ASSEMBLY INSTRUCTIONS
3
A
Install real wheels (B) to power washer unit (A).
This step does not require any screws.
Note:
5
J
D
1
Pull back on collar at the other end of the high
pressure hose (D). Push firmly to connect hose to
spray gun (J). Twist collar to secure. Confirm hose is
locked into spray gun by slightly pulling on it. The hose
is now securely attached to spray gun.
94630_Take-Along_1900PSI_IM_EN.indd 7
B
2
3
D
4
D
HIGH PRESSURE HOSE ASSEMBLY
Screw high pressure hose (D) clockwise onto bottom
front of power washer unit (A). Pull back collar and
insert o-ring post into water outlet far enough so
collar can thread onto outlet threads until hand tight.
If it takes fewer than six turns you have not properly
tightened the high pressure hose fitting. It is easier to
position the power washer in front of you to ensure that
the threads are started correctly. Failure to properly
tighten high pressure hose will result in the hose
slipping or popping off immediately upon turning unit
on. Do not worry about damage if this occurs–just
reinstall and take extra care when screwing on the high
pressure hose fitting.
NOTE: DO NOT use pliers or locking pliers to tighten.
6
J
3
D
2
Twist collar then pull back to release the the high
pressure hose (D) connection from the gun (J).
A
1
3
D
7
