1 Wheelchair overview

1
12
11
10
13
14
15
16
17
18
2019-08-16
9 8
19
Instructions for use Loop
2
3
4
1 Push bail
2 Headrest
3 Side guard
4 Seat cushion
5 Footrest
6 Caster fork
5
7 Swivel caster
8 Brake pressure bolt
9 Driving wheel
10 Handrim
6
11 Clamp lever height adjustment
7
push bail
12 Drum brake operating lever
13 Push bail
14 Tripping lever for (seating unit) tilt
mechanism
15 Eccentric clamp for angle adjustment
of push bail
16 Wheel cover
17 Driving wheel
18 Trigger for angle adjustment of the
back
19 Side guard
20 Brake lever of the knee lever brake
21 Swivel caster
20 21
