5 Close the Safety Bar. Place table tray on the Cardiohelp.
Step-1
6 Attach the Flow/Bubble Sensor between the white marks
on the Red Line (arrow in the direction of flow).
7 Connect the green Gas Tube between the gas source
and the Gas Filter attached to the HLS Module.
Step-1
3
8 Hang the Prime Bag on the IV Pole ensuring that the Inlet
and Outlet are unobstructed and not folded over. Close
2 Stopcocks at top of the bag and close the Clamp on the
Blue Line of Prime Bag.
9 Add 1.5 to 2 l of Physiological Solution via the spike of the
Prime Line. Close the clamp on the Prime Line.
