Cardiohelp System

Preparation and Installation

1 Open Safety Bar. Connect Integrated Sensor Cable and

Flow/Bubble Sensor. Connect Venous Probe and place

probe in stand-by position attached to the safety bar.

2 Install the red HLS Module on the Cardiohelp drive.

Step-1

C A R D I O H E L P S E T U P G U I D E

3 Attach sampling lines if desired and close all stopcocks.

Secure all 3 Luer lock connections, but leave the yellow

cap off the De-airing Membrane.

Closed

Opened

4 Connect the Integrated Sensor Cable to the HLS Module.
