3.4 LEDs

The table below describes the LED on the AppBox C21 CPU Board.
LED NAME
LED1

3.5 Test Points

This section discusses the test points on the AppBox C21 CPU Board. All test points are on the top side of
the circuit board. Their location is shown in the diagram in section 3.0. The table below describes the test
points on the AppBox C21 CPU board.
TEST POINT NAME

4.0 Physical Characteristics

The physical characteristics of the AppBox C21 are described below:
Enclosure (with flanges): 5.83 in(148.26 mm) x 5.13 in(130.5 mm) x 1.10 in(27.94 mm)
C21 CPU Board (without connectors): L: 4.15 in(105 mm) x W: 2.36 in(60 mm)
C21 CPU Board (width with connectors): W: 2.77 in (70.5 mm)
C21 CPU board (maximum height): H: 0.59 in (15 mm)
Weight of enclosure with controller Module: 6 ounces (.17 kg)
Operating Temperature: -0C to +70C
Storage Temperature: -40C to +85 C
Relative Humidity: 0 to 90% (non-condensing)
Maximum power consumption of controller Module: 1 amp at +12 volts
RoHS Compliant: Yes
COLOR
Green User control, PA15_PWM(N)
SIGNAL PRESENT
TP1 Input DC voltage, (+12-24 vdc)
TP2 VDD_5V, +5 volts
TP3
TP4 Pin 7, U5, LIN_VSUP
AppBox C21 System User's Guide
MEANING
DGND
