The table below lists all the interfaces on the AppBox C21 CPU Board.
INTERFACE NAME

3.1 Connectors

The following section describes the connectors on the AppBox C21 CPU Board.
INTERFACE NAME
J1
J2
J6
EXT1
EXT2
EXT3
AppBox C21 CPU BOARD INTERFACES
TYPE OF INTERFACE
J1 Connector for power input
J2 Connector for RS485/CAN/LIN
Connector for header 5x2
J6
EXT1 Connector to AppIO Module
EXT2 Connector to AppIO Module
EXT3 Connector to AppIO Module
JP1 SMT jumper(bottom)
JP2 SMT jumper(bottom)
JP3 SMT jumper(bottom)
JP4 SMT jumper(bottom)
JP5 SMT jumper(bottom)
JP6 SMT jumper(bottom)
JP7 SMT jumper(bottom)
JP8 SMT jumper(bottom)
JP9 SMT jumper(bottom)
SW1 Pushbutton switch
SW2 4 position DIP switch
LED1
TP1
TP2
TP3
TP4
TYPE OF INTERFACE
Connector for power input,
2 position
Connector for RS-485/CAN/LIN,
10 position, 2 x 5
Connector for header 5x2
Connector to AppIO Module #1,
20 position, 2 x 10
Connector to AppIO Module #2,
20 position, 2 x 10
Connector to AppIO Module #3,
20 position, 2 x 10
AppBox C21 System User's Guide
Cortex-M Debug
Green LED
Test point
Test point
Test point
Test point
MATING CONNECTOR
Amphenol Anytek
Terminal Block Plug, 2 pos
TJ0231530000G
TS02315A0000G
Molex 10 Position Rectangular
Housing Connector Receptacle
Natural 0.165" (4.20mm)
0039012100, 0039000038
Cortex-M Debug tail
12
