3.0 Interfaces
This section describes the interfaces on the AppBox C21 CPU Board. These interfaces include the
connectors, jumpers, switches, LEDs, and test points.
The location of each of these interfaces is shown in the figure below:
LED1
TP4
SW1
J2
J1
TP2
TP1
AppBox C21 CPU Board Interfaces
AppBox C21 System User's Guide
TP3
EXT1
EXT2
SW2
J6
EXT3
11
