Electrical installation

• To ensure maximum self-locking ability, please be sure that the motor is shorted when stopped. Actuators with integrated controller
provide this feature, as long as the actuator is powered.
• When using soft stop on a DC-motor, a short peak of higher voltage will be sent back towards the power supply. It is important when
selecting the power supply that it does not turn off the output, when this backwards load dump occurs.
The power supply for actuators without integrated controller must be monitored externally and cut off in case of current overload.
Recommended for actuators without integrated controller
fuse
Type
36120xxxxxxAxxxxF...
36120xxxxxxAxxxxG...
36120xxxxxxAxxxxH...
36200xxxxxxAxxxxF...
36200xxxxxxAxxxxE...
36120xxxxxxBxxxxF...
36120xxxxxxBxxxxG...
36120xxxxxxBxxxxH...
36200xxxxxxBxxxxF...
36200xxxxxxBxxxxE...
36120xxxxxxCxxxxF...
36120xxxxxxCxxxxG...
36120xxxxxxCxxxxH...
36200xxxxxxCxxxxF...
36200xxxxxxCxxxxE...
36120xxxxxxDxxxxF...
36120xxxxxxDxxxxG...
36120xxxxxxDxxxxH...
36200xxxxxxDxxxxF...
36200xxxxxxDxxxxE...
Spindle Thrust max.
Pitch (mm) Push/Pull
(N)
12 2600
12 4500
12 6800
20 1700
20 500
12 2600
12 4500
12 6800
1700
20
20 500
2600
12
12 4500
12 6800
20 1700
20 500
12 2600
12 4500
12 6800
20 1700
500
20
Typical Amp. at full load
(A)
48 V 36 V 24 V
- - -
- - -
- - -
- - -
- - -
- - 10.4
- - 10.2
- - 10.3
-
- 10.3
- - 10.0
8.0
- -
- 8.0 -
- 8.0 -
- 8.0 -
- 8.0 -
7 - -
7 - -
7 - -
7 - -
7
- -
Page 11 of 92
© 2020 LINAK A/S

Recommended fuse

12 V 48 V 36 V
21.0 - -
20.7 - -
21.0 - -
22.0 - -
20.0 - -
- - -
- - -
- - -
- - -
- - -
- - 16.0
- - 16.0
- - 16.0
- - 16.0
- - 16.0
- 10.0 -
- 10.0 -
- 10.0 -
- 10.0 -
- 10.0 -
24 V 12 V
- 40.0
- 40.0
- 40.0
- 40.0
- 40.0
20.0 -
20.0 -
20.0 -
20.0 -
20.0 -
- -
- -
- -
- -
- -
- -
- -
- -
- -
- -
