Adjusting an Objective Correction Collar for a Slide
To adjust an objective correction collar for a slide:
1. In the CellReporterXpress software, on the Home page, click
2. Click Add Protocol.
3. Click New Slide Acquisition.
4. In the Available Acquisition Devices list, select the instrument.
5. On the left side of the screen under Steps, click
6. On the right side of the screen under Tools, click
7. In the Slide Format list, select the slide format.
8. On the right side of the screen under Tools, click
9. In the Objectives list, select the objective.
If a correction collar adjustment is required, the software displays the recommended
setting.
5063669 E
Chapter 3: Objective Maintenance
Acquisition.
Acquisition Settings.
Slide Format.
Objectives.
