Calibrating An Objective - Molecular Devices ImageXpress Pico Calibration Kit Manual

ImageXpress Pico Automated Cell Imaging System Calibration Kit Guide

Calibrating an Objective

After you install a new objective from an after-sales purchase, you must calibrate it. A
calibration kit, which is included with any after-sales objective purchase, includes the
following:
Fluorescent Bead Slide (9100-0099)
Red Plastic Slide (1-GP-7)
Green Plastic Slide (1-GP-8)
Orange Plastic Slide (1-GP-11)
You will need to provide the following item for the calibration process:
4-Slide Holder (5068503)
To calibrate an objective:
1. In the CellReporterXpress software, on the Home page, click
2. Click
calibrate an objective.
3. Click the Objectives tab.
16
Show Device Options to expand the details for the device where you want to
Devices.
5063669 E
