ImageXpress Pico Automated Cell Imaging System Calibration Kit Guide
Replacing an Objective (Different Magnification)
You must install objectives in specific slots in the turret. See
12 for details. Because of this, the only reason to replace an objective with another objective
of a different magnification is when you are a swapping the 40x objective and the 63x
objective in slot 5.
To replace an objective with an objective of a different magnification:
1. In the CellReporterXpress software, on the Home page, click
2. Click
want to replace an objective.
3. Click the Objectives tab.
4. In the tile for objective slot 5, click
5. Click the Choose Objective drop-down list box, and select the objective you want to
install.
6. Click Open Maintenance Door.
7. Remove the objective to be replaced from the instrument by gently turning it
counterclockwise.
8. Install the replacement objective in the slot by gently turning it clockwise.
9. Do both of the following:
a. Manually close the maintenance door.
b. In the CellReporterXpress software, click Close Maintenance Door.
10. Click Apply.
After you replace an objective, you may need to calibrate it. See
page 16
14
Show Device Options to expand the details for the instrument where you
CAUTION! When not installed in the instrument, an objective should always be
stored in its case.
CAUTION! Retain the objective case for future storage needs. When not installed
in the instrument, an objective should always be stored in its case.
for details.
Installing an Objective on page
Component Exchange.
Calibrating an Objective on
Devices.
