5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS
Models: H137WSUA...C & H137WS18...C Series

ELECTRICAL SPECIFICATIONS:

Model No.
H137WSUA12C
H137WSUA9C
H137WSUA5C
H137WSUA6C
H138WS185C
H138WS1834C
H138WS1816C
H137WSUA12C208
H137WSUA9C208
H137WSUA5C208
H137WSUA6C208
H138WS185C208
H138WS1834C208
H138WS1816C208
H137WSUA12C240
H137WUA9C240
H137WSUA5C240
H137WSUA6C240
H138WS185C240
H138WS1834C240
H138WS1816C240
NOTE: The above model numbers are basic models.
They may be followed by letters: M, L, D or ending with S and/or Z.

HOW TO INSTALL UNIT:

1. Place cabinet on level fl oor.
2. Plug cord end into proper wall outlet.
3. Fill water pan with 4 gallons (15 liters) of water.
Use of treated or soft water may be required for
proper operation and to maintain warranty.
4. Place the cabinet in a well-ventilated area.
5. Push the switch to "On", turn the "Air" thermostat
to No. 9 and run the unit for one hour.
NOTE: DO NOT PUT FOOD IN CABINET! This
step is to burn off manufacturing oils and
excess adhesive.
6. Let the cabinet cool and wipe inside clean with
detergent and hot water before fi rst use.
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Humidity Holding Hot Cabinet
Volts Watts Amps
120 2000
208 2000
240 2000
Hertz Phase
16.7 60
9.6 60
8.3 60
WARNING
Air is VERY HOT when door is opened.

HOW TO PROOF:

1. Fill water pan with
2. Turn power switch to "ON".
3. Turn "AIR" thermostat to "PROOF" (No. 1).
4. Turn "HUMIDITY" thermostat to No. 3½.
5. Preheat for ½ hour (30 minutes).
6. Put fresh or fully thawed dough into cabinet.
NOTE: Do NOT put in frozen dough.
NOTE: The optional digital thermometer display
fl ashes when temperature in center of cabinet
is below 140°F/60°C or above 250°F/121°C.
Call the factory if you need different settings.
Insulated
FL-2253
Hot Cabinets
Rev. 15 (6/08)) Page 1 of 6
NEMA
1 5-20P
1 6-15P
1 6-15P
HOT water.
