Cres Cor H-339225 Series Operating And Maintenance Instructions

5925 Heisley Road • Mentor, OH 44060-1833
OPERATING and MAINTENANCE INSTRUCTIONS

ELECTRICAL SPECIFICATIONS:

MODELS:
H-339225-01 / HOT CABINET TOP
H-339225-02 / PROOFER BOTTOM
H-339SS1814CBE / HOT CABINET ONLY
HOW TO INSTALL UNIT: (Figure 1)
See FL-2211-BE (enclosed) for "Stacking
Instructions".
1. Plug cord into receptacle in back of the unit.
2. Turn plug clockwise to lock.
3. Plug other end into 15-amp wall outlet.
4. Place cabinet in a well ventilated area.
5. If no casters are provided, the base must be sealed
to the counter or floor with grout or caulk to
maintain sanitation certification.
6. Push the switch on, turn the thermostat to No. 10
and run the unit for one hour.
NOTE: DO NOT PUT IN FOOD! This step is to
burn off manufacturing oils and excessive
adhesive.
6. Let the cabinet cool and wipe inside clean with
detergent and hot water before use.
HOW TO OPERATE UNIT: (Figure 2)
1. Push switch "ON". Yellow light will come on.
2. Preheat cabinet for 45 minutes; the cabinet
temperature is factory preset.
4. Put food into cabinet.
To Turn Off Unit:
Push switch "OFF". The yellow light will go off.
NOTE: The digital thermometer will flash if cabinet
temperature is below 140°F/60°C or above
250°F/60°C.
Call the factory if you need different settings.
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
For INSULATED HAND-LIFT CABINETS
MODEL H-339225 and H339SS1814CBE
Volts Watts Amps
120 900
120 900
120 900
FIG. 2
Insulated
Hand-lift Cabinets
Rev. 8 (5/13)
Hertz Phase
7.5 60
7.5 60
7.5 60
THERMOSTAT
THERMOMETER
COVER
SWITCH
FL-0520-BE
Page 1 of 4
NEMA
1 5-15
1 5-15
1 5-15
FIG. 1
