Arjo System 2000 Rhapsody Quick Reference Manual page 2

Hydromassage (optional)
Risk of
entrapment
Install the suction cover
before use.
Hydrosound (optional)
Never use
when pregnant.
Fill up with water to cover the
Hydrosound system Transducer Plate.
Add Hydrosoundwater conditioner.
Shower the patient
18 19
Open the drain. Raise the back rest. Let the
patient hold on to the hand rest.
22
Risk of scalding
Press the trigger on the shower handle.
Check the water temperature with a bare
hand. Adjust temperature if needed.
End the bath
26 27
Dry the patient. Keep the patient warm using
towels or a bathrobe.
30
Risk of
pinching
Help the patient to move the legs over the rim
while rotating the lift away from the bathtub.
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com
A
B
Fill up with water to cover the
Hydromassage system outlet
(A) and top sensor (B).
Risk of
burns and
hearing
damage.
Do not touch the Transducer
Plate and keep patients
head above water.
20
Lower the bathtub to its lowest height.
23
Let the patient feel the water by hand
before directing the water stream on the
patient. Adjust temperature if needed.
28
Lower the bathtub to its lowest height.
31
Make sure there is enough space between
the bathtub side and lift hygiene chair.
08.AR.08_1EN • 09/2020 • Page 2/2
-
Press the Hydromassage system button.
The default runtime is 15 minutes.
Start with low intensity. Adjust if needed.
Press the Hydrosound system
button. The default runtime is
15 minutes.
24
Shower the patient.
32
Lower the lift hygiene chair.
Dry the remaining wet areas.
+
Adjust the direction
of the water-jet.
20
P300
After treatment,
P220
turn off the
Adjust the Hydrosound
Hydrosound intensity. system.
21
Take the shower handle. Press the shower
button. Direct the shower handle away from
the patient.
25
Unlock the shower handle trigger if
lock button is activated.
Press the shower button.
Return the shower handle.
29
Raise the lift hygiene chair enough to give space
between the patient's genitals and the bathtub rim.
33
Risk of contamination
After each patient:
clean and disinfect the
bathtub according to
the instructions in the
IFU or Cleaning and
disinfection QRG.
After treatment,
turn off the
Hydromassage
system.
7
7
