NAV 10E 501 and NAV 10E 101 • Setup Guide (Continued)
• USB (NAV 10E 501 only, see
Lit steadily – The encoder is actively sending and receiving a NAV USB stream.
•
• Blinking – The encoder is unable to establish a NAV USB stream.
• Unlit — The encoder is not actively sending and receiving a NAV USB Stream.
E
USB LEDS (NAV E 501 only) — Indicates the status of the USB stream, as follows:
Host
•
• Lit steadily – The encoder is in USB host mode, the default condition.
• Unlit – The encoder is in USB device mode.
• Active
Lit steadily – A host or USB device is connected to the rear panel USB port.
•
• Unlit – No host or USB device is connected to the rear panel USB port.
• Blinking – A USB device or hub is connected to the encoder and is drawing more power than the USB port can supply.
F LAN LEDs
— Indicates status of the network connection.
• NAV LED (NAV 10E 501) or LAN LED (NAV 10E 101) —
• Link LED — Lit steadily indicates that a network link is established at 10G.
• Act LED — Blinking indicates network traffic. The blink rate corresponds to activity.
Ext LED (NAV 10E 501 only) —
•
• Link LED — Lit steadily indicates that a network link is established at 1G. Blinking indicates a link speed less than 1Gbps.
• Act LED — Blinking indicates network traffic. The blink rate corresponds to activity.
G ID button and LED
when the encoder is in pairing mode (see
Operation
Power
When power is applied, the encoder runs a series of self-tests that blink the front panel Power LED and all other indicators. The encoder
then boots the NAV operating system. It can take approximately 45 seconds for self-test and system startup to complete. When the
process is complete, the Power LED lights steadily.
NOTE encoder
The
:

System Operation

The encoder can be configured and controlled using embedded web pages or Extron Toolbelt (see the NAV 10E 501 and NAV 10E 101
User Guide available at www.extron.com
The
"Connection via web pages,"
NOTE:
NOT be necessary if your system includes a NAVigator System Manager
Connection via web pages
Connection to the encoder and its embedded web pages can be made via either the front panel Configuration (USB) port (using IP over
USB technology) (see figure
Access the encoder using HTML pages as follows:
Start a web browser.
1.
:
NOTES
• Suggested browsers to fully support the NAV system are: Google Chrome™, Mozilla™ Firefox™, and Microsoft
• The network must be properly configured for multicasting (IGMP). Failure to do so may result in degraded performance.
Enter the IP address of the encoder in the browser Address field.
2.
figure 2 on page 2)
— The recessed ID button identifies the encoder to the NAVigator and decoder when pressed. The LED blinks
Pairing devices via front panel
is NOT operational until the boot process is complete (the Power LED is lit steadily)
and the Toolbelt Help file).
Connection
2, on page 2) or the rear panel NAV 10G port (see
A
on page 5 for details).
settings, and Pairing devices via front panel
.
figure
.
procedures (see page 5) may
1, on page 1).
F
®
Edge™.
3
