Ethernet; 24 V Dc Power; Antenna - Hubbell GAI-Tronics HUBBCOM GSC1100 Quick Start Manual

™
HUBBCOM GSC1100/GSC2100 Dual-Port DT/WM Smart Controllers
Table 3. Terminal Block TB2—RS-485 and External Speaker
Purpose
RS485 Ground
RS485 B
RS485 A
External Speaker −
External Speaker +

Ethernet

HUBBCOM smart controllers have dual Ethernet ports. Use the RJ45 jack furthest from the USB port to
connect to the Ethernet network. The RJ45 jack closest to the USB port can be used to connect a PC (see
Figure 4).
1. Plug the Ethernet cable from the network into the RJ45 port furthest from the USB port.
2. (Optional) Plug an Ethernet cable from a PC into the remaining RJ45 jack(see Figure 4).

24 V DC Power

Use external 24 V dc power in place of POE (optional) or for units with external speaker hook-ups
(required). Complete the following steps to terminate the 24 V dc power source to the smart controller:
1. Install ferrules onto the wire ends.
2. Insert each wire into the correct quick release terminal (see Table 4).
Purpose
24 V dc Positive
Ground

Antenna

Use the provided SMA (Sub-Miniature connector A) coaxial connector to connect an antenna.
N : Connecting a HUBBCOM smart controller via WiFi disables the secondary Ethernet port.
OTE
N : Use a customer-supplied antenna in flush-mount installations. FCC, IC, ETSI/CE, and TELEC
OTE
Certified with PCB, Dipole, Chip, and PIFA Antennae. GAI-Tronics Kit No. 12840-001
(purchased separately) meets the antenna requirements.
