PRECAUTIONS

Read and understand all instructions before beginning installation.
NOTICE: For installation by a licensed electrician in accordance with National and/or local Electrical Codes and the following instructions.
Disconnect switch or a circuit breaker must be provided and marked as the disconnecting device.
Disconnect switch / circuit breaker must be within reach of operator.
CAUTION: RISK OF ELECTRICAL SHOCK. Turn power off at service panel before beginning installation. Never wire energized electrical components.
CAUTION: USE COPPER CONDUCTOR ONLY
Confirm device ratings are suitable for application prior to installation. Use of device in applications beyond its specified ratings or in applications
other than its intended use may cause an unsafe condition and will void manufacturer's warranty.
NOTICE: Do not install if product appears to be damaged.
SAVE THESE INSTRUCTIONS!

DESCRIPTION

Hubbell Control Solutions' NX Room Controller is a self-contained intelligent power pack. It contains either one or two independently controlled
outputs. Optional 0-10VDC outputs are available for controlling dimmable ballasts and LED drivers. The NX Room Controller also features four Smart
Ports that provide plug and play support for NX occupancy sensors, daylight sensors and manual control switches. The NX Room Controller can
operate stand alone or networked with other NX controls.

SPECIFICATIONS

Max Load Rating
Dimming
Operating Temp
Certifications
Warranty

INSTALLATION

1. DO NOT DISCARD THE INCLUDED MAC ADDRESS LABELS. SEE STEP (5) BELOW.
2. Turn power off at the service panel.
3. Mount the Room Controller (RC) to the outside of a junction box using the Room Controller's extended ½" chase nipple. Secure to box with
enclosed EMT nut. (See Figure 1)
4. The Room Controller has a MAC address label affixed to the outside of the unit. Place the enclosed MAC address label(s) in a log book and record
the location of the Room Controller and the circuit(s) it controls. The MAC address will be needed later during the system setup process.
5. If control devices (e.g. occupancy sensors, daylight sensor and switches) are going to be used, attach them to any available Smart Port with the
appropriate CAT5 device cable. Similar devices (e.g. switches) may be daisy chained together from the same Smart Port. ( See Figure 2)
6. Electrically connect the Room Controller to the circuit(s) as shown in Figure 3. Reapply power at service panel.
7. Test installation as follows:
a. Momentarily press Button A to toggle Load A (red wire) ON and OFF
b. Momentarily press Button B to toggle Load B (blue wire) ON and OFF (2 Relay Models Only)
c. With Load A ON, press and hold Button A down to dim Load A down.
Release Button A and press again to dim Load A up.
d. With Load B ON, press and hold Button B down to dim Load B down.
Release Button B and press again to dim Load B up.
Copyright © 2018 Hubbell Control Solutions, a division of Hubbell Lighting, Inc. All rights reserved. All product and company names, logos and product
identifiers are trademarks ™ or registered trademarks ® of Hubbell Lighting, Inc. or their respective owners. Use of them does not necessarily imply any
™
701 Millennium Blvd. | Greenville, SC 29607 | (864) 678-1000 | (866) 898-0131 - fax www.hubbellcontrolsolutions.com
affiliation with or endorsement by such respective owners.
INSTALLATION INSTRUCTIONS
120/277/347VAC (SPST)
20A Incandescent
20A Magnetic Ballast
16A Electr
onic Ballast/Driver
1HP motor load
0-10VDC, Class 2, Current sink, 60mA per channel
0°C to +40°C
Conforms with UL916 and Certified to CAN/CSA C22.2 #205-12
Plenum rated
Five-year limited warranty
NX Room Controller
72-00646
