- Page 1 Aperio ® AH40 Hub Installation Guide Experience a safer and more open world...
-
Page 2: Table Of Contents
AH40 - Table of Contents AH40 - FCC and ISED Canada Statements ............3 AH40 - Placement of Communication Hub ............. 5 AH40 - Mounting, Americas Adapter Plate ............6 AH40 - Mounting, Bottom Cover ................. 7 AH40 - Connectors ....................8 AH40 - Jumpers...................... -
Page 3: Ah40 - Fcc And Ised Canada Statements
AH40 - FCC and ISED Canada Statements FCC Statements Changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the users authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. - Page 4 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 5: Ah40 - Placement Of Communication Hub
AH40 - Placement of Communication Hub < 2 Example of placement of the Hub with 8 locks. AH40 can manage up to 64 locks Note: AH40 must be installed into a junction box ex European 2-Gang, Aperio bottom cover or with Americas adapter plate to junction box. -
Page 6: Ah40 - Mounting, Americas Adapter Plate
AH40 - Mounting, Americas Adapter Plate (US version) AH40 - Mounting, Americas Adapter Plate Americas Adapter Plate Screw (4 x 35 mm) Top Cover Screw (3 x 10 mm) Option External Antenna... -
Page 7: Ah40 - Mounting, Bottom Cover
AH40 - Mounting, Bottom Cover AH40 - Mounting, Bottom Cover (EU version) Bottom Cover Screw Screw Top Cover (4 x 35 mm) (3 x 10 mm) Option External Antenna... -
Page 8: Ah40 - Connectors
AH40 - Connectors PAIR J200 J400 8-24V J700 J800 S100 onneCtors esCription Ethernet connector. Connection to the Electronic Access Control system through a 10BASE-T / 100BASE-TX Local J700 Area Network. Can also be used for power supply if connected to a IEEE 802.3.af compliant Power Sourcing Device (PSE). -
Page 9: Ah40 - Jumpers
AH40 - Jumpers PAIR J200 J400 8-24V J700 J800 S100 umpers esCription Select external antenna by connecting the two right pins. J400 ANTENNA Select internal antenna by connecting the two left pins. Select pairing mode by connecting the two right pins. J200 Note: If the pairing jumper if removed within 10 seconds PAIR... -
Page 10: Ah40 - Communication Hub Led Indications
AH40 - Communication Hub LED Indications The Communication Hub has a status LED visible through the front cover. It supports optical schemes with red, green and yellow. The indication schemes are described by the figure below: Online Green Aperio Lock Green + One ®... -
Page 11: Ah40 - Technical Data
AH40 - Technical Data Physical Dimensions 82 mm x 82 mm x 37 mm (H x W x T) Power Supply 8-24 VDC or Power over Ethernet (PoE) The power supply shall be able to deliver minimum 1.2 W and be 3 A over current protected. Wire Power Rating requirements 16-22 AWG. - Page 12 www.assaabloy.com/aperio Experience a safer and more open world...
