Installation Manual
MagLink LX4
M2050-EU
Revision: 1
Part Number: M2050-EU, Rev. 1
Issue Date: TBD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MagLink LX4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dover MagLink LX4

Summary of Contents for Dover MagLink LX4

  • Page 1 Installation Manual MagLink LX4 M2050-EU Revision: 1 Part Number: M2050-EU, Rev. 1 Issue Date: TBD...
  • Page 2 Fax +39 0362 1581464 Copyright Information © 2020 Dover Fueling Solutions. All rights reserved. DOVER, the DOVER D Design, DOVER FUELING SOLUTIONS, and other trademarks referenced herein are trademarks of Delaware Capital Formation. Inc./Dover Corporation, Dover Fueling Solutions UK Ltd. and their affiliated entities.

  • Page 3: Table Of Contents

    7.8 Close and Start Up the Console 7.9 DB9 Connections to a Management System 7.9.1 DIALOG Fuel Management System 7.9.2 GILBARCO Fuel Management System 7.9.3 DRESSER (PIGNONE) Fuel Management System Section 8 Maintenance M2050-EU Rev.: 1 Dover Fueling Solutions Page 3...
  • Page 4 Section 9 Technical Support Section 10 Wiring Diagrams 10.1 Connect XMT-SI probes 10.2 Connect XMT Exd probes 10.3 Connect RF Probes 10.4 Connect On/Off Sensors M2050-EU Rev.: 1 Dover Fueling Solutions Page 4...

  • Page 5: Section 1 Preface

    Making copies, citing quotes or other reproductions of all or part of this document is permitted only after written consent of Start Italiana S.r.l. Patents protect trademark or name. Copyright 2019© Start Italiana S.r.l. – All rights reserved M2050-EU Rev.: 1 Dover Fueling Solutions Page 5...

  • Page 6: Section 2 General Warnings

    You must read and obey all safety instructions in this manual before you use this equipment. WARNING: Incorrect use of this equipment that does not agree with the instructions in this manual can cause a risk to safety. M2050-EU Rev.: 1 Dover Fueling Solutions Page 6...

  • Page 7: Section 3 Introduction

    M2052-EU MagLink LX4 User Manual You must install the console as shown in this manual, configure the console as instructed in the M2051-EU MagLink LX4 Configuration Manual, and use the console in the field as shown in the M2052-EU MagLink LX4 User Manual.
  • Page 8 INFORMATION: The units of measurement contained in this manual refer to a specified selection by the user. Refer to the M2051-EU MagLink LX4 Configuration Manual for more information on how to set units of measure. M2050-EU Rev.: 1 Dover Fueling Solutions...

  • Page 9: Safety Warnings

    3.2 Information Panels NOTE: This panel gives more information about an instruction or procedure. IMPORTANT: This panel contains special information that is important and must be read and obeyed. M2050-EU Rev.: 1 Dover Fueling Solutions Page 9...
  • Page 10 This panel shows information that has been given before in the manual that is important to show again. TIP: A step or procedure that is recommended to make another step or procedure easier. INFORMATION: This panel shows references to more information in other sources. M2050-EU Rev.: 1 Dover Fueling Solutions Page 10...

  • Page 11: Section 4 General Indications

    Section 4 General Indications The MagLink LX4 console is shipped in a cardboard box (L 450 x H 300 x D 200 [mm]) and includes the components as follows: MagLink LX4 console Connection cable (220 V AC with Schuko plug)
  • Page 12 For USB printer connection. It can also be used for firmware updates and back-up of the console (Refer to the M2052-EU MagLink LX4 User Manual) For console configuration, and local network connections (Refer to the M2051-EU MagLink LX4 Configuration RJ45...

  • Page 13: Section 5 Product Labels

    Year of production Power Supply(VAC and Hz) Power consumption (VA) Operating temperature (°C) Ingress protection (IP grade) Fuse rating Indication that inside there is intrinsically safe circuit Name and address of the manufacturer M2050-EU Rev.: 1 Dover Fueling Solutions Page 13...
  • Page 14 Equipment Type (BRA-SI, BRA-SIP, or BRA-2SIP) ATEX Reference number of the certificate ATEX Marking: Ex II (1) G [Ex ia Ga] IIB Serial number Electrical data M2050-EU Rev.: 1 Dover Fueling Solutions Page 14...

  • Page 15: Section 6 Installation

    Flammable fumes can cause an explosion when mixed with air. Dangerous areas can occur where there are gases or fumes. The MagLink LX4 console is NOT explosion-proof. WARNING: Only use fuses of 250 V - 1 A for input power.

  • Page 16: Electrical Connection

    The power cord must be easy to identify and must have easy access so it can be used to remove power. WARNING: There is high voltage within the console. IMPORTANT: The electrical connection procedure must be done by approved personnel only! 6.4 Installation Procedure M2050-EU Rev.: 1 Dover Fueling Solutions Page 16...
  • Page 17 (see the illustration above for the locations of the holes). c. Use a pen to identify the screw hole locations on the wall. d. Drill the holes at the screw hole location marks. M2050-EU Rev.: 1 Dover Fueling Solutions Page 17...
  • Page 18 Tap the holes for an applicable screw size or put screw anchors in the hole. It is recommended to use size 6 Fischer wall anchors. f. Attach the unit to the wall with the applicable screws. M2050-EU Rev.: 1 Dover Fueling Solutions Page 18...

  • Page 19: Section 7 Connections

    BRA-2SIP barrier for connection to the DMP-SI-485 and XMT-SI-485 probes (8+8) Four (4) Built-in Relays, Six (6) Inputs, OPTIONAL IFSF/GSM card (International Fore- court Standards Forum/Global Systems for Mobile Communications) 7.1 Connection to the Intrinsically Safe XMT-SI and DMP-SI Probes M2050-EU Rev.: 1 Dover Fueling Solutions Page 19...

  • Page 20: Connection To The Xmt Explosion-Proof Probe

    CN7. It does not go through the intrinsically safe barrier (the barrier is not applicable in this installation). The table that follows shows the wiring connections between the XMT Probes and the LX4 Console main board CN7 terminal block: M2050-EU Rev.: 1 Dover Fueling Solutions Page 20...

  • Page 21: Connection To The Rf Receiver (For Xmt-Si-Rf)

    Blue (RS485B) - Terminal 3 Brown (RS485A) - Terminal 2 Red (+ 12V) - Terminal 1 Refer to the RF Receiver installation manual's section on electrical connections for the correct connections of the receiver. M2050-EU Rev.: 1 Dover Fueling Solutions Page 21...

  • Page 22: Interface To Relay - Diagram Of Connectors

    7.4 Interface to Relay - Diagram of Connectors The illustration above shows the connections of a MagLink LX4 Console. The table that follows shows the console connections: M2050-EU Rev.: 1 Dover Fueling Solutions Page 22...
  • Page 23 CN10 4 - Not Enabled 5 - Not Enabled 6 - Not Enabled 7 - Not Enabled CN11 Main Board Connector The table that follows identifies the Connectors and related status LEDs: M2050-EU Rev.: 1 Dover Fueling Solutions Page 23...

  • Page 24: Ifsf Option

    Input 4 status LED (Terminal 5) Input 3 status LED (Terminal 4) Input 2 status LED (Terminal 3) Input 1 status LED (Terminal 2) Relay 1 status LED (On = relay energized) 7.5 IFSF OPTION M2050-EU Rev.: 1 Dover Fueling Solutions Page 24...

  • Page 25: Dip-Switch Configuration

    Off, turn on the console) IMPORTANT: The general reset results in loss of all configuration data, the his- tory, alarms, delivery and reconciliations! OFF = Reconciliation deactivated ON = Reconciliation activated M2050-EU Rev.: 1 Dover Fueling Solutions Page 25...

  • Page 26: Micro Sd Card

    7.9 DB9 Connections to a Management System The console can be connected through the RS232 port Com 1 on these management systems: DIALOG ORPAK DOMS PIGNONE FUEL POS (VR350 Interface) Probe emulation GILBARCO (VR350 interface) RETALIX M2050-EU Rev.: 1 Dover Fueling Solutions Page 26...

  • Page 27: Dialog Fuel Management System

    PIN 5 PIN 5 Connect PIN 4 with PIN 6 7.9.2 GILBARCO Fuel Management System Console (DB9) GILBARCO System (RJ45) PIN 2 PIN 8 PIN 3 PIN 1 PIN 5 PIN 4 M2050-EU Rev.: 1 Dover Fueling Solutions Page 27...

  • Page 28: Dresser (Pignone) Fuel Management System

    PIN 8 PIN 3 PIN 1 PIN 5 PIN 4 IMPORTANT: Do not use cabling longer than 15 meters (3.2 feet) for RS232 serial connections between the console and the management system. M2050-EU Rev.: 1 Dover Fueling Solutions Page 28...

  • Page 29: Section 8 Maintenance

    Do not use compressed air or liquid detergents to clean the touchscreen or the console. Clean the touchscreen and the outside of the console with a monitor/TV cleaning cloth. M2050-EU Rev.: 1 Dover Fueling Solutions Page 29...

  • Page 30: Section 9 Technical Support

    Dover Fueling Solutions Technical Support personnel. If access to the Internet is not available, the user must give Dover Fueling Solutions Technical Support personnel the applicable data and logfiles related to the console so a debugging procedure can be done.

  • Page 31: Section 10 Wiring Diagrams

    Section 10 Wiring Diagrams 10.1 Connect XMT-SI probes M2050-EU Rev.: 1 Dover Fueling Solutions Page 31...

  • Page 32: Connect Xmt Exd Probes

    10.2 Connect XMT Exd probes M2050-EU Rev.: 1 Dover Fueling Solutions Page 32...

  • Page 33: Connect Rf Probes

    10.3 Connect RF Probes M2050-EU Rev.: 1 Dover Fueling Solutions Page 33...

  • Page 34: Connect On/Off Sensors

    10.4 Connect On/Off Sensors M2050-EU Rev.: 1 Dover Fueling Solutions Page 34...
  • Page 35 Spec for I.S wiring to 4.0 mm2, wir- ing diagrams updated, Connections 1836 12/3/2020 graphics, updated support. Barrier label NOTE: It is possible that older software versions might not support all features M2050-EU Rev.: 1 Dover Fueling Solutions Page 35...
