- Page 1 user manual Multi-Washer 3OOO Series with EvoClean...
- Page 2 index 1.OO overview page 1.01 Safety Precautions 1.02 Overview 1.03 Package Contents 1.04 Panel Dimensions 2.OO installation 2.01 Preliminary Tasks 2.02 Panel Mounting 2.03 Peripheral Elements 2.04 Tubing 2.05 Electrical Connections 3.OO programming 3.01 General 3.02 Unit Parameters 3.03 Channel Parameters 3.04 Product Parameters 3.05 Water Parameters 3.06 Washer Extractor Parameters...
- Page 3 1.OO overview 1.O1 Safety Precautions WARNING! Please read precautions thoroughly before operation. Meet all applicable local codes and regulations. THANK YOU FOR YOUR INTEREST IN OUR PRODUCTS Please use this equipment carefully and observe all warnings and cautions. • Both the unit and its peripheral elements must be handled by qualified technical personnel. •...
- Page 4 1.OO overview 1.O3 Package Contents Multi-Washer 3000 with EvoClean Metric Models HYDSPD0093M 4P, 3WE, 1CH, EVCL, V, MET HYDSPD0091M 6P, 3WE, 1CH, EVCL, V, MET HYDSPD0092M 8P, 3WE, 1CH, EVCL, V, MET North America Models Multi-Washer 3000 with 6-Product EvoClean HYDSPD0093 4P, 3WE, 1CH, EVCL, V, USA HYDSPD0091...
- Page 5 2.OO installation (continued) 2.O3 Peripheral Elements After placing the unit, it is necessary to hang the distributor that directs dosages to the washers: • This distributor is responsible for diverting the products to the corresponding washer extractor. • Only one machine is attended while the others are queued. •...
- Page 6 2.OO installation (continued) 2.O5 Electrical Connections Inside Control Cabinet Bottom of Control Cabinet Main Input Power: Connect a 110 to 230 VAC source to the X1 connections in the cabinet. Weidmuller DC OK Ajust 22-28V PROeco 3-5A Char.C Remember never to get the power from a washer extractor. L(+) N(-) An independent 10 amp breaker is recommended.
- Page 7 2.OO installation (continued) 2.O5 Electrical Connections (continued) Formula Selector Wiring: (Metric Models) With the Metric Multi-Washer 3000 units, the Formula Selector(s) are connected directly to the control board, at the second level of the X2 terminal block, as shown below. Brown to “-”, Yellow to “+”, White to A3 and Green to B3. If multiple Formula Selectors are being connected, they must be connected in parallel, either at the control board or (recommended) using a standard terminal box, as shown.
- Page 8 2.OO installation (continued) 2.O5 Electrical Connections (continued) Washer Signals (North America Models) The signal wires from each washer connect to their Multi- Washer Communications Box using the row of connectors at the lower edge of the circuit board, with the grounds jumpered to have a common connection, as shown to the right.
- Page 9 3.OO programming Programming the Multi-Washer 3000 controller consists of “Creating a Program Settings File”. Follow the steps detailed below to create a program settings file that contains the settings you desire. 3.O1 General 1) From a laptop or smartphone connect to the unit WIFI by connecting to multitec_3_ xxxx. •...
- Page 10 3.OO programming (continued) 3.O2 Unit Parameters (continued) 2) Name – enter the name you wish to give the unit. 3) Enter machine type – Multitec 3. 4) Range • Washer extractors – the amount of washer extractors you are connecting the unit to. •...
- Page 11 3.OO programming (continued) 3.O4 Product Parameters 1) Click on Products in the left-hand column, the below page will open. Product Parameters 2) Product – choose the valve number you want to program i.e. 1. Remember the product order starts with the valve next to the water one.
- Page 12 3.OO programming (continued) 3.O5 Water Parameters 1) Click on Water in the left-hand column, the below page will open. Water Parameters Channel number – dependent on how many channels the unit has, if more than 1 select other numbers to check and save parameters.
- Page 13 3.OO programming (continued) 3.O6 Washer Extractor Parameters (continued) 4) Properties: • Kg/Lb – Enter the wash capacity of the machine in Kilograms or pounds (depending on MW3 model). • Kg/Lb sel – yes or no, this is dependent on whether you have installed a selector to manually change the % wash weight on the unit.
- Page 14 3.OO programming (continued) 3.O6 Washer Extractor Parameters (continued) 6) Washing process: (continued) 7) Trigger mode – Sequential, Signal + 1st Phase, sequential + 1st phase or signal + repetition. 8) Finish mode – signal or pump. Choose whether you want the unit to end the program via a pump or signal (signal number, i.e.
- Page 15 3.OO programming (continued) 3.O7 Formulas (continued) Formula Settings 4) Repeat the above steps for each signal/phase that chemical is to be added. 5) Click on Save at the bottom of the page. 3.O8 On-line View 1) Click on On-line View in the left-hand column, the page shown below will open. On-line View 2) From the windows displayed in the on-line view you will be able to the status of the machines, which programs are running and what signals have been received.
- Page 16 3.OO programming (continued) 3.O9 Upload/Download 1) Click on Upload/Download in the left-hand column, the below page will open. Upload/Download 2) From this screen you can upload the settings you have entered within the programmer on your computer/tablet etc or download from the unit. 3) Click on Save at the bottom of the page.
- Page 17 3.OO programming (continued) 3.11 Manual Dosage 1) Click on Manual Dosage in the left-hand column, the below page will open. Manual Dosage Settings 2) From this page you can enter the desired product, dosage, machine and whether you want flush to create a manual dosage.
- Page 18 4.OO operation 4.O1 Start-Up After having installed the unit, carry out the start-up by following the steps below. Previous requirement and unit configuration Make sure that the laundry is created in Hydro Connect and the equipment is registered in it. In this way the obtaining of statistical data will be enabled.
- Page 19 5.OO service parts General Orientation Description MW 3000 Control Cabinet EvoClean Dispenser (4, 6 and 8-product models available) Water Inlet Assembly Weidmuller DC OK Ajust 22-28V PROeco 3-5A Char.C L(+) N(-) Multi-Washer Cabinet Inside Outside Key Part No. Description HYD1161M3P1CV Multi-Washer 3000 Control Board HYD5753NSYTRV42SF5 Fuse Connector Kit, with 3 Amp Fuse HYD57351000005...
- Page 20 5.OO service parts (continued) Water Inlet Assembly Key Part No. Description HYD11MA11650001 Complete Water Inlet Assembly HYD541708400260 1/2” Check valve with internal spring for injection HYD11172001 Flow meter for MW3000 Series 331610836104 Water pressure regulator + accessories HYD54808400239 PP Barb 1/4” x 12mm Tube, with O-Ring 6.OO warranty 6.O1 Limited Warranty Seller warrants solely to Buyer the Products will be free from defects in material and workmanship under normal use and...
