Summary of Contents for Welbilt Convotherm OES mini easyStart
- Page 1 Combi oven Read instructions before use OES mini easyStart Operating instructions - Original, ENG...
-
Page 3: Table Of Contents
Table of Contents Table of Contents easyStart at a glance Working with the easyStart: what you need to know as store manager Layout of the touchscreen pages Cooking using easyStart Cooking one product Cooking - starting several products at once Cooking - starting several products one after the other Stopping cooking programs before they have finished Cleaning using easyStart... -
Page 4: Easystart At A Glance
1 easyStart at a glance 1 easyStart at a glance 1.1 Working with the easyStart: what you need to know as store manager About this easyStart user manual These operating instructions for easyStart are a supplement to the user manual of the combi oven. It serves the following purposes: This section provides you an overview of how to work with the easyStart. - Page 5 1 easyStart at a glance Basic cooking operation using easyStart The easyStart makes cooking very simple and only involves these 7 steps: Step Action How to do it: Switch on the combi oven. See instructions in user manual: Turning the combi oven on and off If you were previously working in the easy‐...
- Page 6 1 easyStart at a glance Options you can change To make it even safer to work with Convotherm easyStart, you can enable the following functions via the easyTouch Service level: SteamProtect: ■ This function is used to remove moisture from the cooking chamber. As a result, far less hot steam/ vapour escapes when the appliance door is opened.
-
Page 7: Layout Of The Touchscreen Pages
1 easyStart at a glance 1.2 Layout of the touchscreen pages Start page: The 'Product group' page The buttons in the start page have the following meanings and functions: Button Meaning Function Illustration Product group Selection of a product group, e.g. Baking Cancel Disabled on this page Clean... - Page 8 1 easyStart at a glance The Shelf levels selection page The buttons on the 'Shelf levels selection' page have the following meanings and functions: Button Meaning Function Illustration Cooking profile Cooking profile, e.g. 'Baguette rolls' is selected. Additional cooking pro‐ Select another cooking profile.
- Page 9 1 easyStart at a glance The Clean page The buttons on the 'Clean' page have the following meanings and functions: Button Meaning Function Illustration Semi-automatic clean‐ Starts semi-automatic clean‐ ing. ConvoClean system Fully automatic cleaning Cleaning level 1: Starts fully automatic clean‐ ing.
-
Page 10: Cooking Using Easystart
2 Cooking using easyStart 2 Cooking using easyStart 2.1 Cooking one product Hot steam / vapour Risk of scalding from hot steam and vapour Escaping hot steam and vapour can cause scalding to face, hands, feet and legs. Open the appliance door as specified in the instructions for safe opening. Never put your head inside the cooking chamber. - Page 11 2 Cooking using easyStart Step What do you want to do? What does your combi oven do? Select the shelf levels that you The shelf levels are selected wish to load with the selected and the prompt to load is dis‐ cooking profile.
-
Page 12: Cooking - Starting Several Products At Once
2 Cooking using easyStart 2.2 Cooking - starting several products at once Hot steam / vapour Risk of scalding from hot steam and vapour Escaping hot steam and vapour can cause scalding to face, hands, feet and legs. Open the appliance door as specified in the instructions for safe opening. Never put your head inside the cooking chamber. - Page 13 2 Cooking using easyStart Step What do you want to do? What does your combi oven do? Select the 'Additional cooking The cooking profiles are dis‐ profiles' button. played for selection. Select your cooking profile. The 'Shelf levels selection' page is displayed.
- Page 14 2 Cooking using easyStart Step What do you want to do? What does your combi oven do? Open the appliance door, re‐ The 'Cooking profiles' page is move the finished product. The displayed. signal will sound until the appli‐ ance door is closed again. Close the appliance door.
-
Page 15: Cooking - Starting Several Products One After The Other
2 Cooking using easyStart 2.3 Cooking - starting several products one after the other Hot steam / vapour Risk of scalding from hot steam and vapour Escaping hot steam and vapour can cause scalding to face, hands, feet and legs. Open the appliance door as specified in the instructions for safe opening. Never put your head inside the cooking chamber. - Page 16 2 Cooking using easyStart Step What do you want to do? What does your combi oven do? Load the selected shelf levels The cooking starts. The first and close the appliance door. cooking program runs. Select an additional cooking The 'Shelf levels selection' page profile that you wish to use for is displayed.
- Page 17 2 Cooking using easyStart Step What do you want to do? What does your combi oven do? Open the appliance door, re‐ The 'Cooking profiles' page is move the finished product. The displayed. signal will sound until the appli‐ ance door is closed again. Close the appliance door.
-
Page 18: Stopping Cooking Programs Before They Have Finished
2 Cooking using easyStart 2.4 Stopping cooking programs before they have finished Your objective You want to stop the cooking program for shelf levels 4 and 5 before it has finished. Stopping cooking programs before they have finished Proceed as follows: Step What do you want to do? What does your combi oven do? -
Page 19: Cleaning Using Easystart
3 Cleaning using easyStart 3 Cleaning using easyStart 3.1 Cold cooking chamber, semi-automatic cleaning Contact with cleaning agents Risk of chemical burns or irritation to skin, eyes and respiratory system. Direct contact with the ConvoClean new cleaning agent or ConvoCare rinse aid will irritate the skin, eyes and respiratory system. - Page 20 3 Cleaning using easyStart Step What do you want to do? What does your combi oven do? Start the semi-automatic clean‐ Cleaning starts. ing program. Please wait. An audible signal is given. You are prompted to use the spray bottle to spray inside the cooking chamber and then to close the appliance door again.
- Page 21 3 Cleaning using easyStart Step What do you want to do? What does your combi oven do? Open the appliance door. The program continues running automatically. Use a jet of water to give a thorough rinse of the suction panel and the area behind it, and then close the appliance door again.
-
Page 22: Hot Cooking Chamber, Semi-Automatic Cleaning
3 Cleaning using easyStart 3.2 Hot cooking chamber, semi-automatic cleaning Contact with cleaning agents Risk of chemical burns or irritation to skin, eyes and respiratory system. Direct contact with the ConvoClean new cleaning agent or ConvoCare rinse aid will irritate the skin, eyes and respiratory system. - Page 23 3 Cleaning using easyStart Step What do you want to do? What does your combi oven do? With the appliance door closed, An audible signal is given. You wait until the cooking chamber are prompted to take out the has cooled down. food and close the appliance door again.
- Page 24 3 Cleaning using easyStart Step What do you want to do? What does your combi oven do? Please wait. An audible signal is given. You are prompted to rinse off the heaters and to close the appli‐ ance door again. Open the appliance door.
-
Page 25: Using The Convoclean System To Clean The Cooking Chamber When Cool
3 Cleaning using easyStart Step What do you want to do? What does your combi oven do? Use a jet of water to give a thorough rinse of the cooking chamber, rack, suction panel and the area behind it. Alternatively, wipe off the cook‐ ing chamber and fittings thor‐... - Page 26 3 Cleaning using easyStart Step What do you want to do? What does your combi oven do? Open the appliance door. The combi oven starts the fully automatic cleaning program. Take out any food left in the oven and remove larger items Warning: of food residues from the cook‐...
-
Page 27: Cleaning The Hot Cooking Chamber Using The Convoclean System
3 Cleaning using easyStart 3.4 Cleaning the hot cooking chamber using the ConvoClean system Requirements Check that the following requirements have been met: No food has been left in the cooking chamber. ■ All containers, baking trays and shelf grills and any other accessories have been removed from the ■... - Page 28 3 Cleaning using easyStart Step What do you want to do? What does your combi oven do? With the appliance door closed, An audible signal is given. You wait until the cooking chamber are prompted to close the appli‐ has cooled down. ance door.
-
Page 29: Preset Cooking Profiles In Easystart
4 Preset cooking profiles in easyStart 4 Preset cooking profiles in easyStart Tried and tested cooking profiles in 6 pre-configured product groups To ensure reliable and dependable cooking results, tried and tested cooking profiles in 6 preset prod‐ uct groups are available both via the easyTouch cookbook and using easyStart. Meat ■... - Page 30 4 Preset cooking profiles in easyStart Baked cordon bleu 210 °C 6 pcs. at 150 g Frozen black plate Baked schnitzel 210 °C 6 pcs. at 190 g Frozen black plate Baked piccata 210 °C 9 pcs. at 90 g Fresh black plate Grilled skewered chick‐...
-
Page 31: Fish Product Group
4 Preset cooking profiles in easyStart 4.2 Fish product group Cooking profiles in the Fish product group Tried and tested cooking profiles in the 'Fish' product group: Product Quantity per GN Condition Accessories 1/1 tray* Sous vide fish 45 °C 12 pcs. at 120 g Fresh 65 mm GN, per‐... -
Page 32: Vegetables Product Group
4 Preset cooking profiles in easyStart 4.3 Vegetables product group Cooking profiles in the Vegetables product group Tried and tested cooking profiles in the 'Vegetables' product group: Product Quantity per GN Condition Accessories 1/1 tray* Steamed leaf spinach 99 °C 600 g Fresh 65 mm GN, per‐... -
Page 33: Side Dishes Product Group
4 Preset cooking profiles in easyStart 4.4 Side Dishes product group Cooking profiles in the Side Dishes product group Tried and tested cooking profiles in the 'Side Dishes' product group: Product Quantity per GN Condition Accessories 1/1 tray* Fried breaded onion 210 °C 800 g Frozen... -
Page 34: Baking Product Group
4 Preset cooking profiles in easyStart 4.5 Baking product group Cooking profiles in the Baking product group Tried and tested cooking profiles in the 'Baking' product group: Product Quantity per GN Condition Accessories 1/1 tray* Rolls 170 °C 12 pcs. at 35 g Frozen, pre-baked, black plate no colour... -
Page 35: Desserts Product Group
4 Preset cooking profiles in easyStart 4.6 Desserts product group Cooking profiles in the Desserts product group Tried and tested cooking profiles in the 'Desserts' product group: Product Quantity per GN Condition Accessories 1/1 tray* Lava cake, baked 150 °C 10 pcs. at 100 g Frozen black plate Baked apples... - Page 37 Item no. Order no. Additional technical documentation can be found in the download center at : www.convotherm.com Welbilt off ers fully-integrated kitchen systems and our products are ® backed by KitchenCare aftermarket parts and service. Welbilt’s portfolio of award-winning brands includes Cleveland™, Convotherm , Delfi...
