SmartRelais 3 Controller
Circuit
No.
board
14 -
15 B2
16 A2
17 +3
18 -
19 B3
20 A3
21 04
22 03
23 02
24 01
25 0+
26 I3
27 I2
28 I1
29 -
30 I+
EN
Explanation
Reader 2: GND
Reader 2: Data line B.
Reader 2: Data line A.
R eader 3: Power supply. Voltage corresponds to V
1 V or 12 V - 1 V (PoE).
Reader 3: GND
Reader 3 / SmartOutput module: Data line B.
Reader 3 / SmartOutput module: Data line A.
Serial interface: Open drain, data line 4.
Serial interface: Open drain, data line 3.
Serial interface: Open drain, data line 2.
Serial interface: Open drain, data line 1.
Serial interface: Power supply. Voltage corresponds
to V - 1 V or 12 V - 1 V (PoE).
IN
Input 3: Push to open. The relay switches as soon as
this contact is connected to I+ (contact 30).
Input 2: Connection of external components.
Input 1: Connection of external components.
Output: GND
Output: Power supply. Voltage corresponds to V
1 V or 12 V - 1 V (PoE).
5. Connections
-
