Victron energy CCGX Manual

Upgrading to v2

Hide thumbs Also See for CCGX:

2020-11-11 18:44

CCGX: Upgrading to v2

Updating a CCGX from v1.74 to a newer version requires a one time manual upgrade.

At this moment, the latest available version is v2.11.

This document explains the one time manual upgrade procedure.

Once upgraded, updates can be installed automatically from the internet again. See

Video

A microSD card is needed. It is not possible to use an USB stick.

The upgrade procedure:

Get a microSD card. The card needs to be formatted with either a FAT or FAT32 ﬁle system.

Preferably use a card of 32GB or smaller, as larger cards are often hard to format with

mentioned FAT ﬁlesystems. The upgrade requires less than 150MB on the card.

Download

venus-upgrade-image-ccgx.zip

Above link always points to the latest available version.

Unzip it, and put its contents on the card.

Click 'Safely remove hardware' or another eject function on your computer.

Victron Energy - https://www.victronenergy.com/live/

1/3

CCGX: Upgrading to v2

here

for details.

Table of Contents

Do you have a question about the CCGX and is the answer not in the manual?

Page 1 CCGX: Upgrading to v2 CCGX: Upgrading to v2 Updating a CCGX from v1.74 to a newer version requires a one time manual upgrade. At this moment, the latest available version is v2.11. This document explains the one time manual upgrade procedure.
Page 2 All settings in the connected devices (Multis, BMV, Solar Charger etcetera) won’t be aﬀected. Also all settings in the ccgx won’t be aﬀected. But still it is good to double check that. Especially double check wiﬁ and/or ethernet passwords and IP conﬁguration.
Page 3 CCGX: Upgrading to v2 the .swu ﬁle is missing on the sdcard. Make sure to unzip all ﬁles on the sdcard the sdcard slot in the CCGX is broken: contact your dealer for a replacement DISQUS View the discussion thread.
