INSTRUCTIONS FOR THE USER

PRODUCT OVERVIEW
4
3
USING THE BURNERS
The flame symbols printed on the side of the control knobs indicate the
correspondence between the knob and the flame size on the burner.
TO IGNITE A BURNER:
Fig 1
Turn the corresponding knob anti-clockwise up to the maximum position (large
flame, fig.1) and press the knob. If you keep the control knob depressed, the
automatic ignition for the burner will operate.
You should hold down the control knob for 15 seconds after the flame on the
burner has lit. If after 15 seconds the burner has not lit, stop operating the device
and open the compartment door and/or wait at least 1 minute before attempting a
further ignition of the burner.
Please keep this instruction manual for future reference
10 Instruction manual C749G
1
Burners
1 Rapid burner
2
2 Semi-rapid burner
3 Auxiliary burner
4 Triple ring burner
Closed
Maximum
Minimum
After this 15-second interval, to regulate the flame you should continue turning
the control knob anti-clockwise until the flame is at a suitable level. The operating
position MUST be at a position between the maximum and minimum position.
To switch the burner off, turn the control knob fully clockwise to the gas off
position. In case of power failure, the burners can be lit by carefully using a match.
USING THE BURNERS
In order to obtain the maximum yield without
waste of gas, it is important that the diameter of
the pan is suitable for the burner potential (see
the following table) to avoid the flame reaching
out past the pan (fig. 2).
Burner Pan Size min.
Auxiliary 120mm
Semi-rapid 160mm
Rapid 200mm
Triple ring 200mm
Use the maximum flame to quickly make liquids reach boiling temperature, and
the reduced flame to heat food or maintain boiling. All of the operating positions
must be chosen between the maximum and the minimum ones, never between the
maximum position and 'off.'
WARNING:
- Do not use cookware that overlaps the edge of the burner.
- When you are no longer using the hob, always check that the knobs are in the
off position.
- If the flame should blow out accidentally, the safety valve will automatically stop the
gas supply after a few seconds. To restore operation, set the knob to the lighting
point and press.
- While cooking with fat or oil, pay the utmost attention as these substances can
catch fire when overheated.
Fig 2
Pan Size max.
140mm
180mm
240mm
240mm
