Lamp Indications - Inner Range concept iq User Manual

Version 1.03 January-2002

2.3 LAMP INDICATIONS.

Lamp
ZONE Lamps When the Zone
1 to 16 is Un-sealed.
(If the "Zone
activity" option
enabled)
AREA Lamps Area is Armed.
A1, A2, A3, A4 (Multi-Area mode
only)
ARM Area/s are armed
in normal mode.
HOME Area/s are armed
in home mode.
FAULT ^ A system input is
currently in alarm.
PWR AC mains OK
ARM & HOME -
FAULT & PWR -
0
NOTES: ^ See "Fault Analysis Lamps" in Chapter 4.6 or the "System Inputs Table".
* Alarm indication takes priority over Isolate indication.
ON OFF
When the Zone
is Sealed.
Area is Dis-armed.
System not armed
in normal mode.
System not armed
in home mode.
No system inputs
are in alarm.
AC mains problem. -
-
-
Used to display values in programming mode.
FLASHING
FAST: *
When there has been an
Alarm / Tamper on the Zone.
SLOW: *
When the Zone has been Isolated.
There has been an Alarm in the
Area.
(Multi-Area mode only)
-
-
FAST: *
A system input has been in alarm
and must be acknowledged.
SLOW: *
When a System Input has been
Isolated.
System is in "Isolate" mode.
(NEXT, 10)
System is in "Master Operations"
mode. i.e. NEXT functions.
7
