2.1 SPECIAL KEY FUNCTIONS

NEXT -Select a Master User operation. (Enter PIN code, press <NEXT> then the Mode number.
HOME -Used to Arm the system, or an individual Area, in Home Mode.
Master User:
-Used to step through programming Addresses (Users or Telephone numbers)
-Used to toggle between Zone Test modes.

2.2 BEEPER INDICATIONS.

2 or 3 Short Beeps:
1 Long Beep:
Continuous Short Beeps*:
*NOTE:
Single Area systems. All Terminals in the system will beep in response to Exit delay, Entry delay or
Auto-arm warnings.
Multi-Area systems. Only Terminals associated with a particular Area will beep in response to that
Area's warning functions. IMPORTANT NOTE: Terminals not associated with an Area will only beep
on Area 1 warning functions.
2. The LED Terminal
CLR
ENTER -Selects the specified programming Address.
PANIC.
FIRE.
MEDICAL. Keys 7 & 9 pressed simultaneously.
REX. (Request to Exit) <OFF> Key.
(Enhanced Terminals only)
AUTO-LOGOFF: The Terminal will automatically
logoff the operator if there is no keypad activity
detected for 30 seconds.
A User, Master or Installer function was successful.
A User, Master or Installer function has been unsuccessful.
Entry Delay Timer, Exit Delay Timer or Auto-arm Warning.
Version 1.03
-Set the data in the current Address to the
Factory Default.
-Clear the data already entered if you have
made a mistake.
-Logoff the Terminal. (Exit the current Mode
of operation)
(After PIN Code and the Address number
have been entered)
-Saves the data entered in a programming
Address.
Keys 1 & 3 pressed simultaneously.
Keys 4 & 6 pressed simultaneously.
