Arrow RH1014-C1 Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
SS01
Model No.
714880716
Storage Area:
129 Sq. Ft.
12,0 m
BUILDING DIMENSIONS * Size rounded off to the nearest foot
*Approx.
Base
Size
Size
10' x 14'
121" x 160 1/4"
3,0 m x 4,0 m
307,3 cm x 407,0 cm
RH1014-C1
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
952 Cu. Ft.
27,0 m
2
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
123 1/4"
162 3/4"
313,1 cm
413,4 cm
697.68615-A1
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Height
Width
97 1/8"
118 1/4"
246,7 cm
300,4 cm
Depth
Height
Width
157 1/2"
95 7/8"
55 1/2"
400,1 cm
243,5 cm
141,0 cm 175,9 cm
Door
Opening
Height
69 1/4"

Advertisement

loading
Need help?

Need help?

Do you have a question about the RH1014-C1 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow RH1014-C1

Summary of Contents for Arrow RH1014-C1

  • Page 1 Owner's Manual & Assembly Instructions SS01 Model No. RH1014-C1 697.68615-A1 Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 714880716 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 129 Sq.
  • Page 3 We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available at your local dealer, Arrow's website arrowsheds.com or call Arrow's Customer Service department 1-800-851-1085) or you...

  • Page 4: Tools And Materials

    PLAN AHEAD..Watch the Weather: Be sure the day you select to install your building is dry and calm. Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Teamwork: Whenever possible, two or more people should work together to assemble your building.
  • Page 5 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in pieces of your building since some contain the assembly of this building. Be familiar with sharp edges.
  • Page 6 In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation. Contact Arrow as outlined on the Ordering Accessories page to place an order.
  • Page 7 Model No. AK100 Heavy-duty galvanized steel bars that New concrete anchor system permits fi t all 10' (3,0 m) wide Arrow buildings. anchoring any size Arrow building They install quickly and easily to directly to a concrete slab. Each kit...
  • Page 8 02/13 We recommend that you purchase accessory items from your local storage building dealer whenever possible; however, because the full line of accessories is not always available from all dealers, Arrow is offering them to you on a direct basis.
  • Page 9 OPTION 1: Directly on ground (earth) Assemble your building directly on level ground (grass, dirt, rock, sand, etc.). If you choose this option Arrow has a simple kit available to provide a fl oor inside the shed to keep stored items off the ground. This kit can be used to support a plywood fl oor (wood not included) or be fi...
  • Page 10 It is important that the entire fl oor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Arrow Anchoring Kit: (Model No. AK4 or 60298) Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base.
  • Page 11 #8-32 Hex Nut (207) (Packed with Screws) Bolt (207) Screw (454) 67468 66646 Peak Cap (6) 66045 6228 Washer (368) (Arrow Logo) Handle (2) Track Support (2) (11 sheets of 40) 66183 67545 66769 66382 Roof Trim Cap Weather Stripping (1)

  • Page 12: Parts List

    Parts List SS12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 6114 Small Right Gable 6115 Small Left Gable 10497 Horizontal Door Brace 7858 Large Right Gable 7859 Large Left Gable 7861 Roof Panel 7862 Right Roof Panel 7863 Left Roof Panel 6301...
  • Page 13 Assembly by Key No. SS13 new...
  • Page 14  8934 Ramp (1) Step 1  Parts Needed For   9367 Front Floor Frame (2) Floor Frame Assemblies  8936 Rear Floor Frame (2) SO14  10387 Side Floor Frame (4) The front fl oor frame is made up of three pieces.

  • Page 15: Frame Assemblies

    Step 2  Parts Needed For   5986 Rear Wall Angle (2)  10391 Side Wall Angle (4) Frame Assemblies SS15 The main frame pieces reinforce the walls. These piece will later be installed at the top edge of the side walls and the rear wall.
  • Page 16 Step 3  Parts Needed For   10386 Roof Beam (12) Roof Beam Assemblies SS16 The roof beams join the two gables 10386 and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at 10386 the center.
  • Page 17 Step 4  Parts Needed For   6403 Door Track Splice (1) Door Track Assembly  9366 Door Track (2) NOTE: The door track assembly supports the Door Track Splice (painted part) sliding doors and reinforces the front wall. It is made up of three pieces. 6403 Using the door track splice, (painted), join the door track...
  • Page 18 Step 5  Front Floor Assembly (1)  Parts Needed For   Side Floor Assembly (2) Floor Frame  Rear Floor Assembly (1) SO18 RIGHT REAR 10387 Assemble the four corners of the fl oor frame using two screws at each corner as shown.
  • Page 19  5284 Right Corner Post (2) Step 6  Parts Needed For   5285 Left Corner Post (2)  Door Track Assembly (1) Posts/Top Frames  Rear Wall Angle Assembly (1) SS19  Side Wall Angle Assemblies (2) NOTE The remainder of the building assembly requires many hours and more than one person.

  • Page 20: Splice Post

    Step 7  Parts Needed For   5287 Rear Splice Post (1) Splice Post  5283 Side Splice Post (2) SS20 STEP The splice posts support the walls. 5287 Position a rear splice post at the center of the rear wall and fasten us- ing 2 nuts and bolts into rear wall angle and 2 screws into rear fl...
  • Page 21 Step 8  Parts Needed For   7311 Door Jamb (2) Door Jamb SS21 The door jambs reinforce the door opening and provide an attractive trim. Fasten the top of the door jambs to the door track with two screws. Do the same for the bottom into frame.
  • Page 22 Step 9  Parts Needed For   9344 Siding Stud (10) Studs/Front Channel  9365 Front Wall Channel (2) SS22 Following dimensions, place studs between corner and splice post. Posi- tion stud inside top angle and fasten with a screw. Rest bottom tab (large hole) out- side fl...
  • Page 23 Step 10  Parts Needed For   9193 Side Siding (5 board) (12)  8736 Rear Siding (5 board) (6) Side/Rear/Front Siding SS23  8737 Front Siding (5 board) (6) Each screw in the wall requires a washer. STEP CORRECT INCORRECT STEP...
  • Page 24  7858 Large Right Gable (2)  7859 Large Left Gable (2) Step 11  Parts Needed For   6114 Small Right Gable (2)  6115 Small Left Gable (2) Gable Assemblies  6085 Roof Beam Bracket (4) ST24 ...
  • Page 25  Left Gable Assemblies (2) Step 12  Parts Needed For   Right Gable Assemblies (2) Gables/Roof Beams  Single Roof Beam Assemblies (4) ST25  6636 Gable Brace (2) Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws.
  • Page 26 Step 13  Parts Needed For   Main Roof Beam Assembly (1) Roof Beam/Braces  6227 Roof Beam Brace (2) SS26 Fasten the track supports to the front gable assembly only, as shown. STEP Wrap the weather stripping along the mating edge of the large left and right gables as shown.
  • Page 27 Step 14  Parts Needed For   7862 Right Roof Panel (1) Right Roof Panel ST27 Installing the roof panels is best done 7863 7862 with a step ladder. Begin installing roof panels at the back right corner of the building. Each screw and bolt 7861 7861 in the roof requires a washer.

  • Page 28: Roof Assembly

    Step 15  Parts Needed For   7863 Left Roof Panel (1)  7861 Roof Panel (2) Roof Assembly  6797 Ridge Cap (3) ST28 Screws To Install a left roof panel at the left Roof Beam rear corner of the roof. Install two roof panels in the sequence shown on previous page.
  • Page 29 Step 16  Parts Needed For   7861 Roof Panel (4) Roof Assembly  6869 Ridge Cap (3) ST29 Install two roof panels 7861 work- ing side to side. Cover the notched areas of the roof panels with strips of weather stripping tape and continue weather stripping the ridge.
  • Page 30  7861 Roof Panel (2) Step 17  Parts Needed For   7863 Left Roof Panel (1) Roof Assembly  6797 Ridge Cap (3) ST30  7862 Right Roof Panel (1) Install two roof panels, left roof panel, three ridge caps 6797 and right roof panel on the front of the roof as before.
  • Page 31 Step 18  Parts Needed For   6893 Left Side Roof Trim (2)  6892 Right Side Roof Trim (2) Roof Trim  6015 Side Roof Trim (2) ST31 Attach the right and left side roof trim to the lower end of the roof panels on each side of the building using screws at each panel overlap.

  • Page 32: Door Assembly

     3719 Door Handle Brace (2) Step 19  Parts Needed For   10472 Right and Left Doors (2) Door Assembly  10497 Horizontal Door Brace (4) SS32  6301 Vertical Door Brace (2) The steps on this page tell how to assemble the right door.
  • Page 33 Step 20  Parts Needed For   Right Door Assembly (1) Door Installation & Adjustment  Left Door Assembly (1) SQ33 Horizontal Door Brace Gable From inside the building, put the Door Track bottom of the right door assembly Door Slide (on your left when you are inside the building) behind door jamb into the...
  • Page 34 Anchoring and Floor Frame XA34 Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
  • Page 35 SOME FACTS ABOUT RUST XA35 SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfi nished edges, or 2.
  • Page 36 RH1014-C1 697.68615-A1 SS36 714880716...
