Arrow HM101267-A1 Owner's Manual & Assembly Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Owner's Manual & Assembly Instructions
SZ01
Model No.
714501210
Storage Area: 115 Sq. Ft.
10,7 m
BUILDING DIMENSIONS * Size rounded off to the nearest foot
*Approx.
Base
Size
Size
10' x 12'
121" X 143 1/4"
3,0 m x 3,6 m 307,3 cm x 363,9 cm
HM101267-A1
RMW1012-B1
Missing Parts, Questions on Assembly?
Call: 1-800-851-1085 or
assist@arrowsheds.com
Do not return to dealer, they are not
equipped to handle your requests.
693 Cu. Ft.
19,6 m
2
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
123 1/4"
145 3/4"
313,1 cm
370,2 cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Height
Width
77 7/8"
118 1/4"
197,8 cm
300,4 cm
RMG1012-B1
VH1012-C1
Depth
Height
Width
140 1/2"
76 5/8"
55 1/2"
356,9 cm
194,6 cm
141,0 cm 165,1 cm
Door
Opening
Height
65"

Advertisement

loading
Need help?

Need help?

Do you have a question about the HM101267-A1 and is the answer not in the manual?

Questions and answers

Related Manuals for Arrow HM101267-A1

Summary of Contents for Arrow HM101267-A1

  • Page 1 Owner's Manual & Assembly Instructions SZ01 Model No. HM101267-A1 RMG1012-B1 RMW1012-B1 VH1012-C1 Missing Parts, Questions on Assembly? Call: 1-800-851-1085 or assist@arrowsheds.com Do not return to dealer, they are not equipped to handle your requests. 714501210 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE Storage Area: 115 Sq.
  • Page 2 We recommend the combined use of an Arrow Floor Frame Kit and an Arrow Anchoring Kit as an effective method of securing your building to the ground (Available by mail order or at your local dealer) or you may construct a base and anchoring system of your choice.
  • Page 3 PLAN AHEAD..Be sure the day you select to install your building is dry and calm. Watch the Weather: Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Whenever possible, two or more people should work together to assemble Teamwork: your building.
  • Page 4 SAFETY FIRST..Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 Roof: amounts of snow on roof can damage building making it unsafe to enter. In snow country, Roof Strengthening Kits are available for most Arrow Buildings for added protection against heavy snow accumulation. Always keep the door tracks clear of dirt and other debris that prevent them from Doors: sliding easily.
  • Page 6 10'x9' (3,0 m x 2,6 m), use 2 kits. Model No. AT101 Heavy-duty galvanized steel bars that Model No. AK100 fit all 10' (3,0 m) wide Arrow buildings. New concrete anchor system permits They install quickly and easily to anchoring any size Arrow building help organize space and create directly to a concrete slab.
  • Page 7 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 8 THIS PAGE LEFT BLANK INTENTIONALLY...
  • Page 9 A. To support a plywood deck B. To be filled with sand. We recommend the combined use of 1. an ARROW FLOOR FRAME KIT and 2. an ARROW ANCHORING KIT as an effective method of securing the building to the ground.
  • Page 10 Below are recommended ways of anchoring. Anchoring into Wood/Post: (Model No. AK4 or 60298) Arrow Anchoring Kit: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) Recommended for use with any suggested base. dia. holes provided in the frames for proper anchoring.
  • Page 11 65109 67468 66646 66045 #8-32 Acorn Nut (4) Peak Cap (2) Washer (428) Handle (2) (Packed with Screws) (Arrow Logo) (11 sheets of 40) 66183 66769 66382 Roof Trim Cap 5971 Door Slide (4) Lower Door Guide (4) (2 right & 2 left)
  • Page 12 Parts List SZ12 Assembly Part Part Quantity Check Key No. Number Description in Carton List 6000 Right Gable 6001 Left Gable 10497 Horizontal Door Brace 6529 Roof Panel 6640 Right Roof Panel 6641 Left Roof Panel 10477 Right and Left Doors 9370 Door Jamb 9374...
  • Page 13 Assembly by Key No. SV13...
  • Page 14 ● ● ● ● ● 8934 Ramp (1) ● Parts Needed For ● ● ● ● ● ● 9367 Front Floor Frame (2) Step 1 ● ● ● ● ● 8936 Rear Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 10392 Side Floor Frame (4) SV14 The front floor frame is made up of three pieces.
  • Page 15 ● ● ● ● ● 5986 Rear Wall Angle (2) ● Parts Needed For ● ● ● ● ● ● 10389 Rear Wall Channel (2) Step 2 ● ● ● ● ● 10390 Side Wall Channel (4) Frame Assemblies ● ● ● ● ● 10393 Side Wall Angle (4) SV15 The main frame pieces reinforce the walls.
  • Page 16 ● Parts Needed For ● Step 3 ● ● ● ● ● 10397 Roof Beam (8) Roof Beam Assemblies SV16 The roof beams join the two gables and support the roof panels. The main roof beam is made up of four pieces overlapped back to back at the cen- 10397 ter.
  • Page 17 ● Parts Needed For ● ● ● ● ● ● 6403 Door Track Splice (1) Step 4 ● ● ● ● ● 9366 Door Track (2) Door Track Assembly NOTE: Door Track Splice (painted part) The door track assembly supports the sliding doors and reinforces the front wall.
  • Page 18 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● Side Floor Assembly (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) SW18 RIGHT REAR 10392 Assemble the four corners of the floor frame using two screws at each STEP...
  • Page 19 ● Parts Needed For ● ● ● ● ● ● 6627 Wall Panel (2) Step 6 ● ● ● ● ● 9374 Front Wall Panel (2) Corners ● ● ● ● ● 6633 Corner Panel (4) SQ19 NOTE Narrow The remainder of the building assembly Side requires many hours and more than one 6633...
  • Page 20 ● Parts Needed For ● Step 7 ● ● ● ● ● Rear Wall Channel Assembly (1) ● ● ● ● ● Side Wall Channel Assembly (2) Mid Frames SR20 The mid frame pieces give rigidity to the side and rear walls. Fasten the rear wall channel across the middle of the rear wall using screws.
  • Page 21 ● ● ● ● ● Door Track Assembly (1) ● Parts Needed For ● Step 8 ● ● ● ● ● Rear Wall Angle Assembly (1) Top Frames ● ● ● ● ● Side Wall Angle Assembly (2) SQ21 The top frame pieces give rigidity to the walls and provide a surface for attaching the gables which support the roof.
  • Page 22 ● Parts Needed For ● Step 9 ● ● ● ● ● 6627 Wall Panel (8) Wall Panels SZ22 STEP Each wall panel has a crimped rib on one side. The crimped rib should go under the rib of the panel that follows Crimped Rib STEP Underneath...
  • Page 23 ● Parts Needed For ● ● ● ● ● ● 9370 Door Jamb (2) Step 10 ● ● ● ● ● 9365 Front Wall Channel (2) Front Channel/Door Jamb SZ23 The door jambs reinforce the door opening and provide an attractive 9365 trim.
  • Page 24 ● Parts Needed For ● ● ● ● ● ● 6000 Right Gable (2) Step 11 ● ● ● ● ● 6001 Left Gable (2) Gable Assemblies ● ● ● ● ● 5971 Roof Beam Bracket (4) SQ24 The gables go on top of the front and rear walls to support the roof beams.
  • Page 25 ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● Step 12 ● ● ● ● ● Right Gable Assemblies (2) Gables/Braces ● ● ● ● ● 6635 Gable Brace (2) SQ25 Lift and fasten a right and left gable, under angle at corner, to the door track and rear wall angle with screws.
  • Page 26 ● Parts Needed For ● ● ● ● ● ● Main Roof Beam Assembly (1) Step 13 ● ● ● ● ● Single Roof Beam Assemblies (2) Roof Beams SQ26 Spread the two halves of the double roof beam and fasten to the gable brace of the front gable.
  • Page 27 ● Parts Needed For ● Step 14 ● ● ● ● ● 6640 Right Roof Panel (1) Right Roof Panel SQ27 Installing the roof panels is best done with a step ladder. Begin Installing roof panels at the back right corner of the building.
  • Page 28 ● Parts Needed For ● ● ● ● ● ● 6641 Left Roof Panel (1) Step 15 ● ● ● ● ● 6529 Roof Panel (2) Roof Assembly ● ● ● ● ● 6869 Ridge Cap (1) SQ28 Install a left roof panel at the left Screws To Roof Beam rear corner of the roof.
  • Page 29 ● Parts Needed For ● ● ● ● ● ● 6529 Roof Panel (2) Step 16 ● ● ● ● ● 6868 Ridge Cap (1) Roof Assembly SQ29 Install two roof panels as you unroll the weather stripping tape, and press it down, install the second ridge cap 6868 overlapping the first ridge cap.
  • Page 30 ● ● ● ● ● 6529 Roof Panel (2) ● Parts Needed For ● ● ● ● ● ● 6641 Left Roof Panel (1) Step 17 ● ● ● ● ● 6869 Ridge Cap (1) Roof Assembly ● ● ● ● ● 6640 Right Roof Panel (1) SQ30 Install two roof panels, left roof panel, ridge cap 6869 and right roof...
  • Page 31 ● Parts Needed For ● Step 18 ● ● ● ● ● 6015 Side Roof Trim (4) Roof Trim ● ● ● ● ● 6014 Side Roof Trim (2) SQ31 Attach the side roof trim pieces to the lower end of the roof panels on each side of the building using screws at each panel overlap.
  • Page 32 ● ● ● ● ● 3719 Door Handle Brace (2) ● Parts Needed For ● ● ● ● ● ● 10477 Right and Left Doors (2) Step 19 ● ● ● ● ● 10497 Horizontal Door Brace (4) Door Assembly ●...
  • Page 33 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 20 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment SQ33 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP...
  • Page 34 Anchoring and Floor Frame XA34hw Anchoring Anchor your building at this time. Floor Frame If you have purchased a Floor Frame Kit you need to install it at this time.
  • Page 35 SOME FACTS ABOUT RUST XA35hw SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
